Поз.
Артикул
Описание
5
EXHAUST PIPE FRONT LEFT
10
EXHAUST PIPE FRONT RIGHT
15
FLANGE GASKET FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, ELIMINATED - NO LONGER REQUIRED
15
FLANGE GASKET , Replaced By: A4424920080
20
SCREW CONNECTOR TO EXHAUST MANIFOLD
22
NUT STRAP TO SUPPORT,5 149419
23
PROTECTIVE PLATE LEFT
24
PROTECTIVE PLATE AT FRAME
25
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
25
SCREW , Replaced By: N304017008027
26
WASHER , Replaced By: N000125008443
26
WASHER EXHAUST MUFFLER TO STRAP
27
NUT , Replaced By: N913004008001
27
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
30
CONNECTOR FRONT LEFT AND RIGHT
35
CONNECTOR , Replaced By: A3834920007
40
FRONT EXHAUST PIPE FRONT LEFT
45
FRONT EXHAUST PIPE RIGHT
50
EXHAUST MUFFLER
90
BRACKET FRONT EXHAUST PIPE,4 726044
90
BRACKET FRONT EXHAUST PIPE
95
CLAMP FRONT EXHAUST PIPE TO BRACKET,4 726044
95
CLAMP FRONT EXHAUST PIPE TO BRACKET
96
SCREW BRACKET TO CROSS CONNECTION STRUT
96
SCREW , Replaced By: N304017008034
100
BRACKET EXHAUST
105
BRACKET RUBBER BUFFER,5 129244
120
RUBBER BUFFER BRACKET TO SUPPORT
125
DAMPING PAD PARTICLE FILTER
130
NUT STRAP TO BRACKET
130
NUT , Replaced By: N910113010000
135
CLAMP REAR EXHAUST PIPE TO BRACKET
145
SCREW , Replaced By: N304017008034
145
SCREW BRACKET TO CROSS CONNECTION STRUT
150
NUT , Replaced By: N913004008001
150
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
RUBBER BUFFER EXHAUST MUFFLER
999
SUPPORT , Replaced By: A3604910016
999
BRACKET , Replaced By: A3834927941
