Поз.
Артикул
Описание
5
HOSE FEED & RETURN 13X1.5 MM, ORDER BY THE METER
8
HOSE WATER DRAIN
8
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
9
FITTING
11
BANJO UNION10/14
11
BANJO UNION HOSE WIDTH, / I.D., 10/16 MM
12
LINE FEED & RETURN
12
LINE AT SENDER UNIT,D 372681
14
CONNECTOR LINE CONNECTION
16
VALVE , Replaced By: A3760980057
16
VALVE
17
UNION NUT RETURN LINE
19
CONNECTOR AT AIR COMPRESSOR, NOT USED
20
HOSE SENDER UNIT
20
HOSE
23
LOOM TIE. CLAMP
23
CLAMP HOSE TO FITTING AND TO OIL TANK
23
CLAMP , Replaced By: N000000000667
23
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
26
WASHER , Replaced By: A3609902340
26
WASHER BRACKET TO LEFT SIDE MEMBER
29
LOOM TIE160 MM
30
LOOM TIE LINE MOUNTING
30
LOOM TIE AIR INTAKE HOSE TO CLAMP
32
BRACKET , Replaced By: A3184280240
32
BRACKET POS. CABLE,XB209706
34
BRACKET AT RIGHT SIDE MEMBER
35
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
36
SCREW SHIFT LEVER TO BRACKET M8X30
36
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
36
SCREW , Replaced By: N910143008002
39
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
40
NUT HORN TO BRACKET M8
41
NUT HORN TO BRACKET M8
42
NUT BRACKET TO FIRE WALL
43
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
43
SCREW BRACKET AND CLAMP M6X20
44
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
44
NUT , Replaced By: N913023006001
47
LOCK WASHER CABLE TO FUSE BOX
50
CLAMP HOSE TO FLANGE AND TO VALVE
50
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
53
LOOM TIE WIRING HARNESS FOR AIR CONDITIONING SYSTEM 205 MM
53
CABLE TIE. LOOM TIE CABLE TO ALTERNATOR
53
LOOM TIE ELECTRIC CABLE MOUNTING
55
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
55
GROMMET BATTERY CABLE TO SIDE MEMBER,LEFT
56
HOSE GREEN
56
INSULATING HOSE CHECK VALVE,CONNECTION "2"
56
INSULATING HOSE , ORDER BY THE METER
56
HOSE VIOLET
56
INSULATING HOSE , ORDER BY THE METER
56
HOSE WITHE
58
BRACKET BRACKET TO LEFT SIDE MEMBER
80
HOLLOW SCREW FUEL FEED,AT WATER SEPARATOR
80
HOLLOW SCREW
83
SEAL RING TO MOUNT FUEL LINES 16X22 - TO A 688 470 00 90
83
SEAL RING INJECTION PUMP
107
HOSE FUEL LINE TO RETURN CONNECTION
141
BRACKET AT RIGHT SIDE MEMBER
