Поз.
Артикул
Описание
10
PEDAL PLATE ACCELERATOR PEDAL
13
ARTICULATION PIECE ACCELERATOR PEDAL
16
SCREW BRACKET TO SIDE MEMBER
19
PIN ACCELERATOR PEDAL TO JOINT
22
WASHER GROUND CABLE
25
COTTER PIN STRAP TO BRACKET
28
STOP
28
STOP
31
NUT ,B 884219
40
ROD ACCELERATOR PEDAL TO LEVER 151 MM,D 351515
43
NUT BATTERY CASE
46
BALL SOCKET ROD TO BALL PIVOT
49
SECURING CLIP. CIRCLIP
52
PIN ROD TO PEDAL PLATE
55
WASHER6,4
58
COTTER PIN ROLLER TO LEVER
70
LEVER BRACKET
73
BUSHING , USED WITH AIR BRAKE
76
FITTED WASHER , USED WITH AIR BRAKE
79
LOCK RING PIN TO BEARING BRACKET, 380.017,080,081,180,181 ONLY FOR SHORT CAB MERCEDES-BENZ
82
GREASE NIPPLE
85
SPRING REVERSING LEVER
88
BALL PIVOT , Replaced By: A3129910120
91
BALL PIVOT
100
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
110
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
