Поз.
Артикул
Описание
6
6
7
11
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
13
SCREW , Replaced By: N910143008000
13
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M8X35
13
SCREW SPEED SENSOR TO REAR AXLE
15
NUT HORN TO BRACKET M8
23
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
23
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
27
27
27
27
27
27
30
FLEXIBLE METAL TUBE FRONT
30
FLEXIBLE METAL TUBE FRONT
30
33
33
CLAMP ,D 292286, Replaced By: A6954920040
33
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
36
51
SCREW CLAMP ON BRACKET
51
HEXAGON HEAD BOLTM8X130,TO A 674 492 00 40
51
SCREW SUPPORT TO ALTERNATOR
77
SCREW BRACKET TO SIDE MEMBER M10X35
205
