Поз.
Артикул
Описание
8
RESERVOIR (RESERVOIR)
8
RESERVOIR , Replaced By: A3504317102
11
RESERVOIR WITH LOCKING CAP
14
FILLER CAP
17
STRAINER
20
WASHER
23
NUT CONTROL ARM TO REAR AXLE
29
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
32
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
47
HOSE FROM RESERVOIR TO MASTER CYLINDER, ORDER BY THE METER
47
HOSE MASTER CYLINDER,OIL TANK,HYDRAULIC LINES
50
MASTER CYLINDER , Replaced By: A3882957206
50
MASTER CYLINDER , Replaced By: A0012959606
50
MASTER CYLINDERM12X1
50
MASTER CYLINDER , Replaced By: A0012959706
50
MASTER CYLINDER CLUTCH M14X1,D 561822
50
MASTER CYLINDER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0012955206, +001A6732900439
53
PLUG
56
CYLINDER. REPAIR KIT REPAIR KIT TO 384 295 70 06
56
REPAIR KIT CLUTCH MASTER CYLINDER TO 388 295 72 06
56
CYLINDER. REPAIR KIT CLUTCH MASTER CYLINDER,5 366604
59
INTERMEDIATE PIECE , Replaced By: A0002950036
62
SCREW
65
ROD , Replaced By: A6882907039
65
ROD CLUTCH PEDAL
65
ROD (PISTON ROD)
68
NUT CLUTCH PEDAL PISTON ROD
71
LINE FROM CLUTCH MASTER CYLINDER TO HYDRAULIC HOSE,D 078431
71
LINE FROM CLUTCH MASTER CYLINDER TO SLAVE CYLINDER,D 078430
71
LINE FROM CLUTCH MASTER CYLINDER TO HYDRAULIC HOSE,012797
83
LINE FROM CONNECTION FITTING TO SLAVE CYLINDER,012797
83
LINE FROM HYDRAULIC HOSE TO CLUTCH SLAVE CYLINDER,D 078431
86
HOSE FROM LINE AT CLUCTH MASTER CYLINDER TO LINE AT CONNECTOR,B 972370
89
GLAND , Replaced By: A0019901667
92
UNION NUT
95
UNION SCREW
95
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
98
FITTING QUICK BREATHER VALVE,REAR, CONNECTION: "23"
101
CLAMP HYDRAULIC LINE TO SIDE MEMBER,RB012797
107
SLAVE CYLINDER CLUTCH ACTUATION
107
SLAVE CYLINDER , Replaced By: A3842957307, +001A3842907939
116
BOOT
122
ROD TO 384 295 73 07
122
ROD TO 384 295 71 07,002 295 04 07,94 07
122
ROD
149
VALVE BREATHER
149
BLEEDER VALVE , Replaced By: A0004310265
152
PROTECTIVE CAPTO001 295 91 07
158
REPAIR KIT CLUTCH SLAVE CYLINDER TO 0012959407,3452957007,3842957107
158
REPAIR KIT CLUTCH SLAVE CYLINDER
158
REPAIR KIT CLUTCH SLAVE CYLINDER
180
BALL SOCKET
182
SCREW PLUG SOCKET TO FRAME
182
SCREW , Replaced By: N304017010002
184
LOCK WASHER FUSE
186
CIRCLIP POWER CYLINDER TO THROTTLE VALVE LEVER
188
CLAMP LINE MOUNTING
191
SHEET METAL SCREW BRACKET TO CAB 4,2X13
194
LOCK WASHER PLUG SOCKET
197
BRACKET OIL LINE ON ENGINE SIDE
200
BRACKET IDLING ADJUSTMENT WIRE CABLE
200
BRACKET COMPRESSED AIR LINE TO BRAKE CYLINDER
203
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
206
NUT
209
CLAMP ,K 147121, Replaced By: N000000000319
212
WASHER (ARTICULATED ROD)
212
WASHER PLUG SOCKET TO BRACKET
216
SCREW BRACKET TO SIDE MEMBER M10X35
999
ROD , NOT USED
999
SEAL RING
999
BOOT
