Поз.
Артикул
Описание
8
OIL LINE AT LONGITUDINAL OIL DUCT & TURBOCHARGER
11
GASKET FLANGE TO TURBOCHARGER
14
SCREW FITTING TO TRANSMISSION M8X32
17
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
17
SPRING WASHER , Replaced By: N000137008212
18
HOLLOW SCREW FUEL LINE TO FEED PUMP
19
SEAL RINGTO 000 553 03 05,000 553 18 05,
29
PIPE ELBOW TURBOCHARGER OIL RETURN,922205
32
GASKET OIL RETURN LINE TO TURBOCHARGER
35
SCREW PIPE BEND TO BRACKET
44
OIL LINE EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
44
OIL LINE EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
53
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
53
SEAL RING TURBOCHARGER OIL RETURN
59
FITTING OIL RETURN TO TIMING CASE,RIGHT
60
SEAL RING AT AIR COMPRESSOR
999
SEAL RING , Replaced By: A4229970040
999
GASKET , Replaced By: A4421870080
999
GASKET , Replaced By: A4421870180
