Поз.
Артикул
Описание
5
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
8
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
8
PLASTIC PIPE8X6 MM, ORDER BY THE METER
14
BANJO UNION CONNECTION OF FUEL LINES
14
BANJO UNION FROM HOSE TO FEED PUMP
14
BANJO UNION FEED
20
CONNECTOR
20
LINE RETURN LINE
23
NUT. UNION NUT RETURN
24
HOSE FEED LINE AND RETURN LINE
26
LOOM TIE. CLAMP HOSE TO HEATING PIPE
26
CLAMP HOSE TO FITTING AND TO OIL TANK
26
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
29
CLAMP , Replaced By: N916017011000
29
CLAMP , Replaced By: N916017011001
29
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
32
HOSE , Replaced By: A3849977082, +001A3829907088
41
CLAMP LINE MOUNTING
44
EDGE GUARD SECTION AT LEFT SIDE MEMBER 85 MM
44
RUBBER SECTION AT LEFT SIDE MEMBER 85 MM
44
EDGE GUARD SECTION AT LEFT SIDE MEMBER 85 MM
47
HOLLOW SCREW
47
HOLLOW SCREW
50
SEAL RING14X18
53
BRACKET COMPRESSED AIR LINE TO SIDE MEMBER
56
SCREW LINES TO BRACKET
62
NUT BRACKET TO SIDE MEMBER
65
SCREW CLAMP TO BRACKET
68
NUT , Replaced By: N913004006001
71
WASHER PLUG SOCKET TO BRACKET
74
CLAMP FUEL LINES TO BRACKET
77
WASHER BRACKET TO LEFT SIDE MEMBER
77
WASHER , Replaced By: A3609902340
80
LOOM TIE LINE MOUNTING
80
LOOM TIE , Replaced By: A3459977390
80
LOOM TIE ELECTRIC CABLE MOUNTING
80
LOOM TIE , Replaced By: A0019978390
999
LOOM TIE AIR INTAKE HOSE TO CLAMP
999
LOOM TIE , Replaced By: A0019978490
999
LOOM TIE LINE MOUNTING
