Поз.
Артикул
Описание
11
RADIATOR , Replaced By: A3445017001
11
RADIATOR , Replaced By: A3445017001
14
RADIATOR CAP
17
SEAL RING
20
SCREW PLUG , Replaced By: N007604018101
23
SUPPORT
26
SCREW BRACKET TO SIDE MEMBER
29
NUT BRACKET TO SIDE MEMBER,XB209706
32
BRACKET RADIATOR,LEFT
38
SCREW DAMPING PAD TO SUPPORT M 8X45,B 884219
38
SCREW 3/2-WAY VALVE TO BRACKET M8X55
38
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
41
WASHER TRAILER PLUG SOCKET TO BRACKET
44
NUT HORN TO BRACKET M8
47
SUPPORT
50
SCREW SUPPORT TO SIDE MEMBER M 10X75,B 884220
53
RUBBER RING SHOCK ABSORBER MOUNTING
56
SPACER TUBE RADIATOR STRUT TO SUPPORT AND TO CAB
59
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
62
NUT OIL COOLER TO BRACKET,TOP
65
RUBBER MOUNTING TRANSMISSION TO INTERMEDIATE RING
68
LOCK WASHER , Replaced By: N912004010102
71
NUT BRACKET TO RETARDER
74
WASHER GROUND CABLE
77
LOCK WASHER , Replaced By: N912004010102
80
NUT BRACKET TO RETARDER
87
FAN SHROUD
98
SCREW PLUG SOCKET TO FRAME
101
WASHER PULL ROD TO SHIFT LEVER
104
LOCK WASHER TAIL LAMP TO BRACKET
107
NUT
