Поз.
Артикул
Описание
5
RESERVOIR AIR RESERVOIRS I AND II 40 L
8
RESERVOIR AIR RESERVOIR III 20 L
11
VALVE DRAIN 20 L
14
VALVE
14
VALVE. DRAIN VALVE DRAIN
14
VALVE DRAIN, Replaced By: A0004322107
14
VALVE DRAIN, Replaced By: A0004322407
14
VALVE
17
VALVE REPAIR KIT TO 384 432 72 07
20
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
20
SEAL RING LINE CONNECTION
21
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
23
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
26
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
29
VALVE (CHECK VALVE)
29
VALVE (CHECK VALVE)
29
VALVE (CHECK VALVE)
32
BASE AIR RESERVOIR TO FRAME,INSIDE,683255
35
FITTING VALVE TO VALVE
38
SEAL RINGTO 006 997 00 72
41
FITTING LOCKING VALVE,CONNECTION: "2"
47
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
50
THRUST RING LOCKING VALVE
50
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
50
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
53
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
56
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
58
SEAL RINGTO 006 997 00 72
63
CONSOLE AIR RESERVOIR
65
CONSOLE AIR RESERVOIR
68
BRACKET
71
SCREW CROSS MEMBER TO CONSOLE M 12X1.5X90,D 132899D 154054
74
NUT SUPPORT TO SIDE MEMBER
77
SCREW METAL SPRING BELLOWS TO WEB
80
NUT BRACKET TO SIDE MEMBER
83
STRAP AIR RESERVOIR TO CONSOLE
86
STRAP AIR RESERVOIR TO FRAME SIDE MEMBER
89
PIN STRAP TO CONSOLE 20 L
92
COTTER PIN , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
95
SCREW EXHAUST PIPE TO BRACKET
98
NUT BRACKET TO RETARDER
101
NUT , Replaced By: N910113010000
110
EDGE GUARD SECTION , ORDER BY THE METER
110
PAD AT CROSS MEMBER
110
RUBBER SECTION AT LEFT SIDE MEMBER 85 MM
110
EDGE GUARD SECTION AT LEFT SIDE MEMBER 85 MM
110
EDGE GUARD SECTION AT LEFT SIDE MEMBER 85 MM
