Поз.
Артикул
Описание
11
PEDAL PLATE ACCELERATOR PEDAL
14
ARTICULATION PIECE ACCELERATOR PEDAL
15
SCREW ARTICULATION ELEMENT TO FLOOR M8X20,D 209703
23
PIN ACCELERATOR PEDAL TO JOINT
26
WASHER GROUND CABLE
29
COTTER PIN STRAP TO BRACKET
62
ROD ACCELERATOR CONTROL
65
NUT BATTERY CASE
68
BALL SOCKET ROD TO BALL PIVOT
71
SECURING CLIP. CIRCLIP
74
PIN ROD TO PEDAL PLATE
77
WASHER6,4
80
COTTER PIN ROLLER TO LEVER
164
LEVER BRACKET
168
FITTED WASHER , USED WITH AIR BRAKE
170
LOCK RING PIN TO BEARING BRACKET, 380.017,080,081,180,181 ONLY FOR SHORT CAB MERCEDES-BENZ
172
GREASE NIPPLE
175
BALL PIVOT , Replaced By: A3129910120
176
BALL PIVOT
179
SCREW PLUG SOCKET TO FRAME
182
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
243
BALL SOCKET FROM REVERSING LEVER TO CONTROL LEVER
243
BALL SOCKET AT CONTROL LEVER
244
NUT
