Поз.
Артикул
Описание
5
STEERING SUPPORT
5
STEERING SUPPORT AT FRAME
8
BRACKET OIL LINES
11
SCREW STEERING BRACKET TO FRAME M 12X1.5X60
11
SCREW , Replaced By: N308676012018
11
SCREW BRACKET TO FRAME M 12X35
11
SCREW VIBRATION ABSORBER TO FRAME M 12X1.5X55
14
WASHER SUPPORT TO FRAME,D 127794
17
NUT ALTERNATOR TO SUPPORT
20
SCREW , Replaced By: N308676018001
20
SCREW BEARING BRACKET AND PLATE TO FRAME M 16X1.5X40
21
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
21
FITTED SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
23
PITMAN ARM AT STEERING GEAR
26
DRAG LINKNAKATA
26
DRAG LINKLEMFOERDER
999
BOOT FIXED PART OF JOINT
999
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
999
BOOT FIXED PART OF JOINT TO 384 460 88 05
999
DRAG LINK END ,K 055088
999
BOOT SCREWED PART OF JOINT
999
JOINT TO BE SCREWED INTO DRAG LINK TO 682 460 98 05
999
DUST CAP SCREWED PART OF JOINT TO 682 460 31 05,98 05,75 05,77 05
999
CLAMP JOINT TO DRAG LINK TO 682 460 75 05
999
COTTER PINROCKINGER TYP 260 G140
999
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
999
NUT SUPPORT TO SIDE MEMBER
