Поз.
Артикул
Описание
5
TORSION BAR REAR AXLE,D 005411
5
TORSION BAR REAR AXLE,D 005411
5
TORSION BAR ,D 005410
6
BUSHING
8
BRACKET SHOCK ABSORBER AND STABILIZER,LEFT
8
BRACKET SHOCK ABSORBER AND STABILIZER,RIGHT
11
RUBBER MOUNTING AT SHOCK ABSORBER BRACKET,D 005410
11
RUBBER MOUNTING ,D 005411
14
BRACKET AT SHOCK ABSORBER BRACKET
17
SCREW BATTERY CASE TO SIDE MEMBER
20
LOCK WASHER SUPPORT TO SIDE MEMBER
23
BRACKET STABILIZER TO FRONT AXLE
26
SCREW CONSOLE TO BRACKET M 12X1.5X25,20 L
26
HEXAGON HEAD BOLT. SCREW SPACER TUBE BETWEEN STABILIZER SHACKLES M14X1,5X80,D 228766
29
NUT ALTERNATOR TO SUPPORT
29
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
32
SCREW BATTERY CASE
35
NUT BRACKET TO BATTERY CASE
38
PLATE. WEB STABILIZER
41
BEARING BRACKET LEFT SIDE MEMBER,D 005410
41
BEARING BRACKET LEFT SIDE MEMBER,D 005411
41
BEARING BRACKET RIGHT SIDE MEMBER,D 005410
41
BEARING BRACKET RIGHT SIDE MEMBER,D 005411
42
BUSHING
44
SCREW BEARING BRACKET AND PLATE TO FRAME M 16X1.5X40
47
SERRATED WASHER BEARING BRACKET AND PLATE TO FRAME
50
GREASE NIPPLE INTERMEDIATE LEVER
53
GREASE NIPPLE
53
GREASE NIPPLE
56
JOINT BEARING TORSION BAR TO LINK,5 903513
56
JOINT BEARING TORSION BAR TO LINK,5 903513
59
LOCK RING TORSION BAR TO LINK,5 903513
62
SPACER TUBE LINK TO BEARING BRACKET,5 903513
65
SEAL RING LINK TO BEARING BRACKET,5 903513
65
SEAL RING TORSION BAR TO BEARING BRACKET,D 005410
68
PIN TORSION BAR TO BEARING BRACKET,D 005410
71
LOCK PLATE TORSION BAR TO BEARING BRACKET,5 904660
74
NUT TORSION BAR TO BEARING BRACKET,5 904660
77
REPAIR KIT REAR STABILIZER,D 005410
80
LINK TORSION BAR TO BEARING BRACKET,D 005410
80
LINK TORSION BAR TO BEARING BRACKET,D 005411
83
SPACER TUBE BEARING BRACKET TO STEERING COLUMN BRACKET
83
SPACER TUBE TORSION BAR TO BEARING BRACKET,D 228766
86
SCREW SPACER TUBE BETWEEN STABILIZER SHACKLES 12X1.5X75,D 228765
86
HEXAGON HEAD BOLT. SCREW SPACER TUBE BETWEEN STABILIZER SHACKLES M14X1,5X80,D 228766
89
NUT SUPPORT TO SIDE MEMBER
89
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
999
SCREW SHOCK ABSORBER TO BOTTOM BRACKET
