Поз.
Артикул
Описание
5
TANK POWER STEERING
8
OIL DIPSTICK ,D 523393
11
FILLER CAP
14
SEAL RING
17
BRACKET
20
FILTER ELEMENT ,D 441028D 523393
25
STRAP OIL TANK
28
SCREWM 10X20
31
SCREWM 10X20
92
95
98
102
108
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
108
CLAMP RETURN AND SUCTION LINES TO FRAME, FRONT
111
CLAMP OIL DIPSTICK TO RADIATOR
114
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
114
CLAMP LINES TO BRACKET
114
CLAMP DELIVERY AND SUCTION LINES TO FRAME
118
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
118
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
121
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
121
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
125
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
128
SCREW , Replaced By: N910143008000
133
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
138
NUT BRACKET TO FIRE WALL
