Поз.
Артикул
Описание
5
ACCELERATOR PEDAL
5
ACCELERATOR PEDAL
8
JOINT
11
SCREW ACCELERATOR PEDAL TO FLOOR PLATE
14
STOP FULL THROTTLE
17
LEVER (PEDAL LEVER)
20
LEVER (PEDAL LEVER)
23
LOCK PLATE
26
BUSHING ,B 892893
29
LEVER (CONTROL LEVER),1B 915840
35
BALL PIVOT INTERMEDIATE LEVER
38
LEVER (CONTROL LEVER)
41
SCREW BRACKET TO FRAME
44
WASHER PLUG SOCKET TO BRACKET
47
NUT PUMP TO BRACKET
50
BRACKET REVERSING LEVER
53
LEVER
56
BALL PIVOT INTERMEDIATE LEVER
59
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
62
COVERING , Replaced By: A4073015088
62
COVERING
65
LOCK PLATE
68
SCREW BRACKET TO DISC WHEEL M 8X16,D 315831
71
LOCK WASHER TAIL LAMP TO BRACKET
74
ROD255 MM
77
ROD305 MM
80
BALL SOCKET PULL ROD TO LEVER
83
NUT
86
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
