Поз.
Артикул
Описание
5
BEARING BRACKET BRAKE PEDAL
5
BEARING BRACKET , Replaced By: A6882947001
8
STUD
20
GASKET BEARING BRACKET TO CAB
20
GASKET , Replaced By: A6452940280
29
SPRING WASHER STEERING SHAFT BEARING TO CAB
32
NUT LEVER TO SHIFTING SHAFT
35
STOP STOP TO BEARING BRACKET
38
STOP CLUTCH PEDAL
41
STOP CLUTCH PEDAL STOP
44
NUT LEVER TO SHIFTING SHAFT
47
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
50
NUT PUMP TO BRACKET
53
STOP
53
STOP
53
STOP
53
STOP BRAKE PEDAL
56
PEDAL (CLUTCH PEDAL)
59
NEEDLE BEARING CLUTCH PEDAL
59
NEEDLE BEARING
62
PIN CLUTCH PEDAL39 MM(M10) TO A6952907216
65
NUT AIR CLEANER ELEMENT
68
PAD , Replaced By: A1072910182
68
PAD CLUTCH PEDAL
140
PIN CLUTCH PEDAL TO BEARING BRACKET
146
WASHER CLUTCH PEDAL TO BEARING BRACKET
155
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
155
LOCK , Replaced By: A6732920073
158
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
167
WASHER PLUG SOCKET TO BRACKET
170
ROD , Replaced By: A3822908419
170
BEARING BRACKET
171
NEEDLE BEARING JOINT TO PIN
171
NEEDLE BEARING JOINT TO PIN
171
NEEDLE BEARING JOINT TO PIN
171
NEEDLE BEARING JOINT TO PIN
173
NUT GEARSHIFT LEVER KNOB TO GEARSHIFT LEVER
176
SPRING RETAINER SPRING TO PUSH ROD
179
SPRING CLUTCH PEDAL RESET,B 974884
182
SPRING RETAINER SPRING TO PUSH ROD
185
CLIP SPRING TO PUSH ROD
188
SPRING PARTS KIT
188
REPAIR KIT , Replaced By: A3862900039
188
ROD , Replaced By: A3822900093
191
PIN , Replaced By: A3842917074
191
PIN PUSH ROD TO CLUTCH PEDAL52 MM,B 910380
197
WASHER BRACKET TO FENDER BRACKET
203
LOCK PLATE
206
LOCK RING PUSH ROD TO PEDAL
