Поз.
Артикул
Описание
127
BRACKET FUEL RETURN AND LEAK LINE
127
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A4220780041
127
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 716010, Replaced By: A4420784741
140
SCREW BRACKET MOUNTING
140
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X40
166
BRACKET FUEL FILTER
170
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
170
SCREW , Replaced By: A0079903901
170
SCREW , Replaced By: N000961012051
170
SCREW , Replaced By: N308676012038
170
SCREW , Replaced By: N308676012012
170
SCREW BEARING BRACKET TO FRAME
170
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
170
SCREW BRACKET TO LEFT SIDE MEMBER
170
SCREW BRACKET TO TRANSMISSION
170
SCREW ENGINE MOUNTING TO CONSOLE M 12X1.5X32
170
SCREW CONSOLE TO FRAME SIDE MEMBER
173
SUPPORT
173
SUPPORT
175
SCREW BRACKET WITH FUEL FILTER TO ENGINE
175
SCREW CONNECTING PIPE
180
LOCK WASHERROCKINGER TYP 59 G140,59 G150
225
BRACKET , Replaced By: A4030920840
225
BRACKET FUEL FILTER
245
INTERMEDIATE PIECE AT INJECTION PUMP
246
SEAL RING INJECTION PUMP
250
SCREW ,5 903514, Replaced By: N000960012353
250
SCREW TRANSMISSION
250
SCREW TORSION BAR TO SHACKLE,5 903514
252
HOSE FROM FILTER TO INJECTION PUMP
253
HOLLOW SCREW FUEL LINE TO FEED PUMP
254
SEAL RING INJECTION PUMP
255
LINE FUEL
255
LINE FUEL
400
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
423
INTERMEDIATE PIECE AT INJECTION PUMP
429
HOLLOW SCREW FUEL LINE TO FEED PUMP
434
BANJO UNION FUEL LINES AND BREATHING
438
SEAL RING INJECTION PUMP
440
HOLLOW SCREW HEATING CONNECTION
440
HOLLOW SCREW FUEL LINE TO FEED PUMP
453
INTERMEDIATE PIECE AT INJECTION PUMP
453
INTERMEDIATE PIECE AT INJECTION PUMP
466
SCREENING NOZZLE HOLDER, TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0119977782, +001A4030780074
466
HOSE LEAK LINE, ORDER BY THE METER
488
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
489
INTERMEDIATE PIECE AT INJECTION PUMP
489
ADAPTER FITTING EXTENSIBLE BRAKE VALVE,CONNECTIONS: "10,20"
489
INTERMEDIATE PIECE EXTENSIBLE BRAKE VALVE,CONNECTIONS: "10,20"
490
VALVE FUEL FILTER
490
VALVE , Replaced By: A0000920610
492
SEAL RING FUEL LINE TO FEED PUMP
504
BANJO UNION FUEL LINES AND BREATHING
504
BANJO UNION HOSE WIDTH, / I.D., 4/14 MM,K 169123
504
BANJO UNION , Replaced By: N000000000364
504
BANJO UNION
506
INTERMEDIATE PIECE (COLLECTING HOSE CONNECTION)
508
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
509
HOLLOW SCREW FITTING LINE CONNECTION
509
HOLLOW SCREW FITTING INJECTION PUMP BLEEDING
590
HOSE LEAK LINE, ORDER BY THE METER
590
SCREENING NOZZLE HOLDER, TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0119977782, +001A4030780074
601
SCREENING PLATE
615
SPRING WASHER , Replaced By: N000137008212
615
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
618
SCREW , Replaced By: N304017008021
618
SCREW , Replaced By: N304017008039
618
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
618
SCREW PIPE CLAMP
620
SEAL RING FUEL LINE TO FEED PUMP
621
OIL LINE RIGHT
623
HOSE FROM FILTER TO INJECTION PUMP
623
HOSE LEAK LINE TO CYLINDER HEAD
626
HOSE FROM INJECTION PUMP TO FILTER
629
BANJO UNION FUEL TANK-TO-FUEL-PUMP FUEL LINE
632
HOSE FROM FILTER TO INJECTION PUMP
635
HOSE
636
FITTING LINE MOUNTING
638
PLUG TO PLUG HYDRAULIC LINE
638
PLUG
641
FITTING LINE MOUNTING
644
T-FITTING FUEL TANK SUPPORT
647
SEAL RING VALVE TO VALVE,K 025179
650
ADAPTER FITTING FROM FUEL PUMP TO FILTER
653
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
656
SCREW STOP TO BATTERY CASE
659
HOSE LEAK LINE, ORDER BY THE METER
662
HOSE LEAK LINE, ORDER BY THE METER
662
SCREENING NOZZLE HOLDER, TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0119977782, +001A4030780074
665
BRACKET , Replaced By: A6205461343
665
BRACKET BATTERY CABLE TO CROSS MEMBER
668
CLAMP CABLE HARNESS MOUNTING
668
CLAMP , Replaced By: N000000001045
668
CLAMP , Replaced By: N916016010211
671
SCREW GROUND CONNECTION, SEE SA 28 101
671
SCREW COVER PLATE TO BRACKET
674
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
677
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
677
HEXAGON NUT. NUT LINE TO SIDE MEMBER
677
NUT , Replaced By: N913023006001
697
BANJO UNION FUEL TANK-TO-FUEL-PUMP FUEL LINE
698
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
699
HOLLOW SCREW
702
INTERMEDIATE PIECE AT INJECTION PUMP
703
INTERMEDIATE PIECE AT INJECTION PUMP
705
SEAL RING INJECTION PUMP
706
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
708
SPRING WASHER CAB FLOOR
709
SCREW , Replaced By: N000961012051
709
SCREW BEARING BRACKET TO FRAME
711
FITTING LINE MOUNTING
712
PLUG
714
CLAMP
715
HOSE LEAK LINE, ORDER BY THE METER
717
HOSE FUEL LINE, ORDER BY THE METER
718
TS DOUBLE FITTING (PARTS KIT),LINE RUPTURE 4MM
719
SCREW PIPE CLAMP
719
SCREW , Replaced By: N304017008021
872
BANJO UNION FUEL LINES AND BREATHING
874
HOLLOW SCREW FUEL LINE TO FEED PUMP
895
FITTING RETURN
897
NUT. UNION NUT RETURN
946
VALVE FUEL FILTER
946
VALVE , Replaced By: A0000920610
952
SEAL RING INJECTION PUMP
999
HOLLOW SCREW
999
SCREW FITTING , Replaced By: A4039971172
999
SCREW BRACKET TO SUPPORT
999
WASHER , Replaced By: N000125008443
999
FITTING
999
HOSE , Replaced By: A6050780581
999
HOSE , Replaced By: A6154760326
999
BRACKET , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 421-422 105120, Replaced By: A4220900441
999
FILTER HEAD
999
BRACKET , Replaced By: A4230900341
999
FILTER , Replaced By: A4420900452
999
BRACKET , Replaced By: A4220901241
999
COVER , Replaced By: A4220920108
999
HOSE , Replaced By: A4079976482
999
BRACKET
999
HOSE , Replaced By: A4079976482
999
BRACKET , Replaced By: A4030900741
999
HOSE , Replaced By: A4279970982
999
HOSE
999
BRACKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A4070900341
999
INTERMEDIATE PIECE , Replaced By: A4470780068
999
OIL LINE
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A0119977782
999
BRACKET
999
BRACKET , NO LONGER AVAILABLE
999
HOSE , Replaced By: A6154760326
999
LINE FROM INJECTION PUMP OVERFLOW LINE TO FUEL FILTER OVERFLOW VALVE
999
LINE FROM PREFILTER TO FEED PUMP
999
ENGINE SUPPORT
999
BRACKET , Replaced By: A4230900341
999
BRACKET , Replaced By: A4030900741
999
BRACKET ,002101
999
BRACKET , Replaced By: A4220900041
999
BRACKET , Replaced By: A4030920540
999
BRACKET FUEL LEAK LINE
999
BRACKET MULTI-STAGE FUEL FILTER
999
HOSE , Replaced By: A6154760326
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A0119977782
999
SCREENING , Replaced By: A4030700055
999
INTERMEDIATE PIECE , Replaced By: A4020700095
999
SPACER TUBE , Replaced By: A3872680153
999
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4030900140
999
FILTER ELEMENT , Replaced By: A4220900051
999
FILTER ELEMENT , Replaced By: A4220900051
999
SPACER TUBE SHAPED HOSE ON AIR INTAKE PIPE
999
FUEL FILTER , 628057
999
BUSHING , Replaced By: A6673210153
999
BRACKET AT TRANSMISSION
999
HOLLOW SCREW ,4 493018, Replaced By: N915047010100
999
HOLLOW SCREW , Replaced By: N915047010100
999
SEAL RING
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A0119977782
999
HOSE , Replaced By: A0139976782
999
PLASTIC TUBE2X4MM, ORDER BY THE METER
999
LOOM TIE , Replaced By: A0019978490
999
CLAMP , Replaced By: N916016011201
999
FUEL FILTER , Replaced By: A4220900152
999
FUEL FILTER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401,402,403 257485 404 005659 421,422,423 051822 424 000441, Replaced By: A4220900152
999
FUEL FILTER , Replaced By: A0014778601
999
FUEL FILTER , Replaced By: A0014778601
999
FUEL FILTER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3244770001, +001A0004777215
999
FUEL FILTER , Replaced By: A0014775701
999
FUEL FILTER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0014774801
999
FUEL FILTER , Replaced By: A4220900252
999
FUEL FILTER , EXHAUST STOCK OF OLD PARTS NUMBER FIRST 035135, Replaced By: A0010921901
999
FUEL FILTER , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 035153, Replaced By: A0010921801
999
FUEL FILTER , Replaced By: A0014775001
999
FUEL FILTER , Replaced By: A0014775001
999
INJECTION PUMP , Replaced By: A0014778601
999
FITTING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0069971672
999
CLAMP , Replaced By: N916016010203
999
CLAMP , Replaced By: N916016010201
