Поз.
Артикул
Описание
5
BEARING BRACKET
5
BEARING BRACKET , Replaced By: A3862947101
11
GASKET BEARING BRACKET TO CAB
11
GASKET , Replaced By: A6452940280
14
SPRING WASHER CABLE TO ALTERNATOR
17
NUT
20
STOP STOP TO BEARING BRACKET
23
STOP CLUTCH PEDAL
26
SCREW LINE MOUNTING
29
NUT STOP TO BEARING BRACKET
32
STOP
32
STOP
32
STOP
32
STOP CLUTCH PEDAL,1B 849449
32
STOP BRAKE PEDAL
32
STOP CLUTCH PEDAL AND BRAKE PEDAL
35
STOP CLUTCH PEDAL STOP
38
NUT BATTERY CASE
41
PEDAL CLUTCH,B 656101
41
PEDAL CLUTCH
41
PEDAL CLUTCH
41
PEDAL CLUTCH,B 924387
44
PAD , Replaced By: A1072910182
44
PAD CLUTCH PEDAL
47
NEEDLE BEARING
47
NEEDLE BEARING CLUTCH PEDAL
50
PIN
50
PIN CLUTCH PEDAL39 MM(M10) TO A6952907216
53
NUT CLUTCH PEDAL
56
PIN CLUTCH PEDAL TO BEARING BRACKET
59
WASHER CLUTCH PEDAL TO BEARING BRACKET
62
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
65
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
68
WASHER PLUG SOCKET TO BRACKET
71
BEARING BRACKET
71
ROD , Replaced By: A3822908419
74
HEX. NUT. NUT SHIFT LEVER KNOB
77
SPRING RETAINER SPRING TO PUSH ROD
80
SPRING SPRING TO PUSH ROD
80
SPRING SPRING TO PUSH ROD
83
SPRING RETAINER SPRING TO PUSH ROD
83
SPRING RETAINER , Replaced By: A3092910091
86
CLIP SPRING TO PUSH ROD
89
PIN PUSH ROD TO CLUTCH PEDAL52 MM,B 910380
92
LOCK RING PUSH ROD TO PEDAL
92
LOCK RING PUSH ROD TO PEDAL
95
WASHER BRACKET TO FENDER BRACKET
95
WASHER BRACKET TO FENDER BRACKET
98
SPRING CLUTCH PEDAL RELEASE SPRING
98
SPRING CLUTCH PEDAL RESET 48 MM,B 924387
101
VALVE"WABCO DO BRASIL"
101
VALVE"KNORR"
101
VALVE"KNORR", USED WITH AIR BRAKE
104
REPAIR KIT SMALL SCOPE TO 345 434 71 01
104
REPAIR KIT SMALL SCOPE TO 000 434 30 01
104
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
104
REPAIR KIT LARGE SCOPE TO 000 434 30 01
104
REPAIR KIT , Replaced By: A0004304106
104
REPAIR KITTO 000 434 22 01
107
HOLLOW SCREW COMPRESSED AIR LINE TO OPERATING CYLINDER
110
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
113
BRACKET CLUTCH PEDAL
116
LEVER
119
ROLLER LEVER
122
BUSHING CLUTCH PEDAL
122
BUSHING OPERATING VALVE
123
RIVET LEVER
125
SCREWM 6X12
128
SCREW CLUTCH PEDAL
131
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
134
NUT LEVER TO SHIFTING SHAFT
137
WASHER GROUND CABLE
140
LOCK RING
999
CUP 3/2-WAY VALVE WABCO
999
HANDLETO 000 434 23 01
999
REPAIR KIT 3/2-WAY VALVE WABCO
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
SEAL RINGTO 000 434 30 01
999
STUD
