Поз.
Артикул
Описание
5
TIMING CASE ,000011
5
TIMING CASE
5
TIMING CASE
10
STUD STARTING MOTOR MOUNTING
15
THREADED INSERT
20
THREADED INSERT ,5 462573
25
THREADED INSERT
30
GUARD PLATE STARTING MOTOR MOUNTING
35
SCREW OIL SCAVENGING
40
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
40
SPRING WASHER , Replaced By: N000137008212
45
EXPANSION PLUG TIMING CASE LOCK
50
GASKET TIMING CASE LOCK
55
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
55
SCREW , Replaced By: N304017008034
60
SPRING WASHER , Replaced By: N000137008212
60
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
65
SEAL RING CRANKSHAFT SEALING,REAR,708527 I.D., 120MM
65
SEAL RING , Replaced By: A0139971447
65
SEAL RING
70
GASKET , Replaced By: A4470150080
70
GASKET TIMING CASE TO CYLINDER CRANKCASE
75
SCREW TIMING CASE TO CYLINDER CRANKCASE,259615
75
SCREW
