Поз.
Артикул
Описание
5
GROMMET
7
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
7
BRAKE HOSE FROM QUICK-RELEASE VALVE TO COMBINATION CYLINDER,RIGHT
7
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
7
BRAKE HOSE , Replaced By: A3844207248
7
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
8
HOSE
9
CLAMP , Replaced By: N916017011001
10
FITTING
11
GLAND , Replaced By: A0019901967
12
UNION NUT LINE CONNECTION, Replaced By: N000000006239
14
LINE LEFT FRONT WHEEL BRAKE CYLINDER
14
LINE RIGHT FRONT WHEEL BRAKE CYLINDER 12X1 MM
17
UNION NUT LINE CONNECTION, Replaced By: N000000006239
20
GLAND , Replaced By: A0019901967
23
CONNECTION FITTING
26
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER,D 030552
26
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER,D 030552
26
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER,D 030552
26
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER,D 030552
26
BRAKE HOSE FROM COMPRESSED AIR LINE TO REAR WHEEL BRAKE CYLINDER,D 030552
44
CLAMP SUCTION LINE TO CROSS MEMBER
44
CLAMP COMPRESSED AIR LINE TO ENGINE CROSS MEMBER,D 216117
56
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
59
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
68
WASHER , Replaced By: A3609902340
68
WASHER BRACKET TO LEFT SIDE MEMBER
71
LOOM TIE , Replaced By: A3459977390
71
LOOM TIE ELECTRIC CABLE MOUNTING
72
LOOM TIE LINE MOUNTING
74
SCREW SUPPORT TO FRAME M12X1,5X35,D 127794
77
NUT ALTERNATOR TO SUPPORT
80
BRACKET , Replaced By: A3454288540
80
BRACKET LINE MOUNTING
83
CLAMP BRAKE HOSE BRACKET
86
SCREW CLAMP TO BRACKET
89
LOCK WASHER CABLE TO FUSE BOX
91
NUT
94
BRACKET POS. CABLE,XB209706
97
BRACKET LINE MOUNTING
100
SCREW METAL SPRING BELLOWS TO WEB
103
SCREW , Replaced By: N304017010040
103
SCREW CROSS MEMBER TO SIDE MEMBERS
104
WASHER SUPPORT TO FRAME,D 127794
105
LOCK WASHER FITTING TO BRACKET
107
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
108
WASHER GROUND CABLE
110
CLAMP
110
CLAMP BRAKE HOSE BRACKET
110
CLAMP , Replaced By: A3829950701
110
CLAMP LINE MOUNTING
110
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
110
CLAMP LINES TO BRACKET
110
CLAMP HOSE TO BRACKET 25/20,5 206397
110
CLAMP COMPRESSED AIR LINES TO BRACKET AT SUBSTRUCTURE
110
CLAMP COMPRESSED AIR LINES TO BRACKET AT SUBSTRUCTURE
111
CLAMP , Replaced By: A6739950001
113
SCREW PLUG SOCKET TO FRAME
116
NUT BRACKET TO SIDE MEMBER
119
SCREW CLAMP TO BRACKET
119
SCREW OVERLOAD PROTECTOR TO BRACKET
122
LOCK WASHER CABLE TO FUSE BOX
125
WASHER PLUG SOCKET TO BRACKET
128
NUT PUMP TO BRACKET
131
BRACKET COMPRESSED AIR LINE MOUNTING
134
BRACKET AT CROSS MEMBER "3"
137
SCREW , Replaced By: N304017010040
140
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
143
CONNECTION FITTING ,TB108828
146
BRACKET COMPRESSED AIR LINE TO BRAKE CYLINDER
146
BRACKET COMPRESSED AIR LINE TO BRAKE CYLINDER
149
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
149
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
152
SCREW CONTROL UNIT
155
WASHER PLUG SOCKET TO BRACKET
158
NUT PUMP TO BRACKET
161
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
161
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
161
TEST CONNECTION
161
TEST CONNECTION
161
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
161
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
161
TEST CONNECTION TIRE INFLATING CONNECTION KNORR
161
TEST CONNECTION TIRE INFLATING CONNECTION KNORR
164
T-FITTING COMBINATION CYLINDER
167
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
168
CONNECTOR FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION "23"
170
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
173
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
173
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
173
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
173
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
173
THRUST RING LOCKING VALVE
173
THRUST RING LOCKING VALVE
176
T-FITTING TRAILER CONTROL VALVE,CONNECTION: "1"
176
T-FITTING AIR RESERVOIR,CONNECTION: "31"
179
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
182
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
188
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
191
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
194
HOLLOW SCREW FITTING LOCKING VALVE,CONNECTION: "11"
197
SEAL RINGTO 006 997 00 72
