Поз.
Артикул
Описание
20
BEARING BODY FAN DRIVE
26
SCREW PLUG
29
SEAL RING PNEUMATIC VALVE
32
SCREW REGULATING VALVE TO BRACKET
38
WASHER TRAILER PLUG SOCKET TO BRACKET
41
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
47
FAN SHAFT
53
BALL BEARING FAN SHAFT
53
BALL BEARING
62
LOCK RING52X2 MM
65
BALL BEARING FAN DRIVE
68
SEAL RING CASE COVER
68
RADIAL SEAL RING , Replaced By: A0019978447
71
HUB FAN DRIVE
74
LOCK WASHERROCKINGER TYP 59 G140,59 G150
77
NUT WEAR INDICATOR
80
FAN
89
SCREW LINES TO BRACKET
92
LOCK FAN TO HUB
98
PULLEY
104
LOCK WASHERROCKINGER TYP 59 G140,59 G150
107
NUT WEAR INDICATOR
119
WASHER2.5 MM
119
WASHER3.2 MM
119
WASHER1.5 MM
122
CAP BOLT. SCREW BALANCING PLATES TO FAN AND TO PULLEY M 6X20
122
CYLINDRICAL HEAD SCREW. SCREW BALANCING PLATES TO FAN AND TO PULLEY M 6X15
122
SCREW BALANCING PLATE TO FAN
125
WASHER PLUG SOCKET TO BRACKET
128
TOOTHED WASHER HANDLE TO RATCHET ROD
131
NUT
134
SUPPORT CLAMPING LEVER,A 112537
134
SUPPORT CLAMPING LEVER
138
STUD
141
NUT FUEL TANK TO SUPPORT
143
SCREW BRACKET TO FRAME M 10X45
146
WASHER GROUND CABLE
149
LOCK WASHER , Replaced By: N912004010102
152
NUT BRACKET TO RETARDER
155
LEVER
158
SCREW BEARING BRACKET TO CAB
161
TIGHTENER PULLEY , 341.250 FROM CHASSIS A 002104
161
TIGHTENER PULLEY , Replaced By: A3902067019
164
GROOVED BALL BEARING
167
SPACER TUBE
171
LOCK RING BELT TIGHTENER
181
SPACER WASHER AS REQUIRED 0.5 MM
181
SPACER WASHER AS REQUIRED 1.0 MM
185
LOCK RING SHIFT LEVER TO PIVOT PIN
188
RADIAL SEAL RING
191
EXPANSION PLUG , 341.250 FROM CHASSIS A 002104
194
GREASE NIPPLE PROTECTIVE TUBE
212
V-BELT , Replaced By: A6649973692
215
V-BELT
215
V-BELT , Replaced By: A0099976892
