Поз.
Артикул
Описание
5
VALVE FRONT AXLE SELF-LEVELLING DEVICE
8
PROTECTIVE CAPWABCO
11
MAGNET ,5 760168K 154651
14
REPAIR KIT AIR SPRING VALVE
17
SCREW CLUTCH TO FLYWHEEL M 8X60
20
NUT
23
SCREW. BANJO BOLT AIR RESERVOIR,CONNECTION: "33",4 872664
26
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
29
FITTING LINE CONNECTIONS
32
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
35
SCREW. BANJO BOLT AIR RESERVOIR,CONNECTION: "33",4 872664
38
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
41
VALVE REAR AXLE
41
VALVE REAR AXLE LEVEL ADJUSTMENT VALVE
44
HEX. HEAD SCREW. SCREW EXHAUST PIPE TO SUPPORT M 8X45
47
WASHER PUMP TO CONSOLE
50
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
53
LEVER REAR AXLE
56
SCREW CABLE HARNESS MOUNTING
59
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
62
BANJO BOLT LEVEL ADJUSTMENT VALVE CONNECTION
62
HOLLOW SCREW HEATING CONNECTION
65
SEAL RING LINE CONNECTION
68
BRACKET BOTTOM
71
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
72
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
74
ROD LEVEL ADJUSTMENT VALVE
74
ROD LEVEL ADJUSTMENT VALVE
77
TRAVEL SENSOR REAR AXLE,K 186868
83
LEVER REAR AXLE
89
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
92
NUT
95
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
98
SCREW LICENSE PLATE TO BRACKET
99
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
101
SCREW CLUTCH TO FLYWHEEL M 8X60
999
BRACKET LEFT OPERATING ROD
999
BRACKET RIGHT OPERATING ROD
