Поз.
Артикул
Описание
9
BRACKET COMPRESSED AIR LINE TO ENGINE
12
BRACKET BATTERY CABLE
12
BRACKET , Replaced By: A3464296040
14
BRACKET COMPRESSED AIR LINE
17
SCREW GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
17
SCREW STEERING SHAFT BEARING TO CAB M 8X20
17
SCREW PIPE CLAMP
20
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
20
SCREW ELECTRICAL COMPARTMENT
20
HEXALOBULAR BOLT GROUND LINE TO GRID HEATER M6X25
26
WASHER COMPRESSED AIR LINE TO BRACKET
38
LOCK WASHER CABLE TO FUSE BOX
38
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
41
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
44
NUT SPRING-LOADED PUSH ROD
44
NUT CROSS MEMBER TO SIDE MEMBERS
56
CLAMP DELIVERY AND SUCTION LINES TO STEERING
62
CLAMP LINE MOUNTING
62
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
62
CLAMP COMPRESSED AIR LINE MOUNTING 38/20
62
CLAMP FRAME MOUNTED CABLE HARNESS TO CAB
62
CLAMP , Replaced By: A3829950701
65
CABLE TIE IONIC EXCHANGER 380X7.8MM
65
LOOM TIE LINE MOUNTING
68
CABLE TIE310X5MM
68
CABLE TIE IONIC EXCHANGER 380X7.8MM
71
WASHER BRACKET TO LEFT SIDE MEMBER
74
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
74
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
77
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
78
SCREW. BANJO BOLT AIR RESERVOIR,CONNECTION: "33",4 872664
80
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
80
HOLLOW SCREW FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTION: "1"
83
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
86
T-FITTING FROM CHECK VALVE TO RELAY VALVE
89
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
92
THRUST RING LOCKING VALVE
95
NUT LINE CONNECTION THROUGH CAB FLOOR M16X1.5
98
ADAPTER FITTING LEFT,DIAPHRAGM CYLINDER
101
VALVE TWO-WAY
101
VALVE (TRAILER CONTROL VALVE) "KNORR"
104
VALVE BODYTO 002 429 95 44
107
SCREW. BANJO BOLT AIR RESERVOIR,CONNECTION: "33",4 872664
110
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
113
T-FITTING HOSE WIDTH, / I.D., 9/16
116
LINE FROM FITTING TO DIAPHRAGM CYLINDER 12 MM,A 069205
119
UNION NUT LINE CONNECTION
122
SEAL CONE LINE CONNECTION
