Поз.
Артикул
Описание
637
VALVE , Replaced By: A0003283230
637
VALVE
638
LEVER , Replaced By: A6523200527
642
FITTING , Replaced By: A0019972572
642
FITTING LINE CONNECTION, Replaced By: N000000006446
645
SEAL RING LINE CONNECTION
648
SCREW PLUG , Replaced By: N000908012009
648
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
657
HOLLOW SCREW LINE CONNECTION
665
NUT , Replaced By: N913004008001
665
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
668
PULL ROD PNEUMATIC SUSPENSION CONTROL
669
YOKE BOTTOM
670
YOKE TOP
671
NUT , Replaced By: N304035008001
671
NUT
672
NUT , Replaced By: N304035008002
672
NUT L.H. THREAD
673
NUT
675
BALL STUD. BALL PIVOT PULL ROD TO BRACKET
676
NUT , Replaced By: N913004008001
676
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
678
VALVE STEERED AXLE SELF-LEVELLING DEVICE
680
BALL PIVOT BOTTOM B13X5 MM
687
BRACKET AIR SPRING VALVE
688
BRACKET LEVEL ADJUSTMENT VALVE CONTROL
699
NUT , Replaced By: N913004008001
699
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
701
PULL ROD FROM INTERMEDIATE LEVER TO ENGINE, TO BE ADAPTED DURING ASSEMBLY
702
YOKE BOTTOM
703
YOKE TOP
704
NUT , Replaced By: N304035008001
704
NUT
705
NUT , Replaced By: N304035008002
705
NUT L.H. THREAD
706
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0004342501
706
VALVE (CHANGE-OVER VALVE) AUTOMATIC LOAD-DEPENDING BRAKE, 415 5 014668 416 5 000515 417 4 972023
711
LOCK PLATE VALVE TO BRACKET
715
BRACKET AUTOMATIC LOAD-DEPENDING BRAKE CHANGEOVER VALVE, 415 5 014668 416 5 000515 417 4 972023
718
SCREW , Replaced By: N304017008027
718
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
723
NUT , Replaced By: N913004008001
723
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
727
RUBBER BUFFER AUTOMATIC LOAD-DEPENDING BRAKE CHANGEOVER VALVE, 415 5 014668 416 5 000515 417 4 972023
728
BRACKET ,4 602074, Replaced By: A3933200543, +001A3933280284
729
BRACKET AUTOMATIC LOAD-DEPENDING BRAKE CHANGEOVER VALVE,4 602075
730
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
730
VALVE TWO-WAY VOSS
736
ADAPTER FITTING RELAY VALVE
737
HOLLOW SCREW , Replaced By: N915047008100
737
HOLLOW SCREW LINE CONNECTION
739
O-RING CHECK VALVE TO AIR RESERVOIR
740
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
741
BRACKET , Replaced By: A3183281840
741
BRACKET , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A3094921819
741
BRACKET AUTOMATIC LOAD-DEPENDING BRAKE SHUTTLE VALVE, 415 5 014668 416 5 000515 417 4 972023
742
SCREW CLAMP TO BRACKET AND TO PIPE
746
NUT , Replaced By: N913004008001
746
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
747
VALVE (CHECK VALVE)
748
VALVE (TEST VALVE), 415 5 014668 416 5 000515 417 4 972023
749
SCREW-IN FITTING LINE CONNECTION
749
FITTING LINE CONNECTION, Replaced By: N000000006446
750
SEAL RING LINE CONNECTION
875
VALVE (CHECK VALVE)
875
NON-RETURN VALVE. VALVE WITH CHECK VALVE WABCO,5 433388
883
T-FITTING 3/2-WAY VALVE
886
O-RING CHECK VALVE TO AIR RESERVOIR
889
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
893
NUT CHECK VALVE TO AIR RESERVOIR
896
T-FITTING EXTENSIBLE BRAKE VALVE, 4 691696
999
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
999
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
999
HOLLOW SCREW HEATING CONNECTION
999
UNION NUT LINE CONNECTION
999
NUT , Replaced By: N910113016001
999
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
999
NUT , Replaced By: N910113010002
999
NUT , Replaced By: N910113010000
999
LOCK WASHER FITTING TO BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
NUT COMBINATION CYLINDER TO BEARING BRACKET
999
NUT CONSOLE TO SUPPORT
999
HEXAGON NUT
999
NUT STRAP TO BRACKET
999
PULL ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
999
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
GREASE NIPPLE
999
SCREW
999
SEAL RING LINE CONNECTION
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
GLAND LINE CONNECTION
999
SCREW , Replaced By: N000963008036
999
SCREW FOR SPRING CLAMPS
999
SCREW BRACKET TO SHIM, 415 5 014668 416 5 000515 417 4 972023
999
SCREW BRACKET TO TORSION BAR,4 9511495 554754
999
SCREW TORSION BAR TO BEARING BRACKET M 16X115,5 903514
999
SCREW SPACER TUBE TO MOUNTING
999
SCREW SHOCK ABSORBER TO TOP BRACKET
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: N304017008016
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008053
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
SPRING LEAFNO.3
999
SPRING LEAFNO.9
999
SPRING LEAFNO.8
999
SPRING LEAFNO.7
999
SPRING LEAFNO.6
999
SPRING LEAFNO.5
999
REPAIR KIT , Replaced By: A3953200165
999
REPAIR KIT , Replaced By: A3953200265
999
REPAIR KIT , Replaced By: A3955860332
999
SHACKLE PIN PARTS KIT
999
SHACKLE PIN PARTS KIT
999
GUIDE SIGN AIR SPRING BELLOWS,LEFT AND RIGHT
999
BRACKET TORSION BAR
999
BRACKET ,4 951148 ONLY REPLACEABLE BY PAIRS, Replaced By: A3933251440, +002N000961010008, +002N913004010010
999
SPRING SEAT TORSION BAR TO REAR AXLE,LEFT,5 554754
999
BRACKET TORSION BAR,RIGHT,5 554754
999
SHIM FRONT SPRINGS TO FRONT AXLE,4 286 049
999
ROD , Replaced By: N900331008421, +001A0004310667, +001A0004310767
999
ADHESIVE FOIL GUIDE SIGN
999
SHIM FRONT SPRINGS TO FRONT AXLE
999
SHIM FRONT SPRINGS TO FRONT AXLE
999
ROD
999
SPRING LEAFNO.10
999
SPRING LEAF , Replaced By: A6593210619
999
SPRING LEAF , Replaced By: A6593210618
999
SPRING LEAF , Replaced By: A6593210617
999
SPRING LEAF , Replaced By: A6593210616
999
SPRING LEAF , Replaced By: A6593210615
999
SPRING LEAF , Replaced By: A6593210713
999
WASHER ANTE-FREEZE DEVICE TO STRAP
999
SPACER TUBE , Replaced By: A3094310249
999
SHIM FRONT SPRINGS TO FRONT AXLE II
999
BUSHING , Replaced By: A3354310053
999
GUIDE BUSHING TWO-WAY VALVE TO FRAME
999
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
FITTING
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
FITTING , Replaced By: A0029905971
999
SEAL RING5X2 MM, 415 5 014668 416 5 000515 417 4 972023
999
SEAL RING4 X 1.50 MM, 415 5 014668 416 5 000515 417 4 972023
999
SEAL RING8X2 MM, 415 5 014668 416 5 000515 417 4 972023
999
LOOM TIE ,4 809255
999
FITTING (PARTS KIT),LINE RUPTURE
999
BALLTO 003 429 22 44
999
REPAIR KIT 3/2-WAY VALVE WABCO
999
HANDLE
999
HANDLE ,5 292411
999
HANDLE , 415 5 014668 416 5 000515 417 4 972023
999
FITTING , Replaced By: A0039979972
999
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
999
REPAIR KITWABCO
999
REPAIR KIT WITH BALL PIVOT TO 393 350 55 05, 658 350 00 05 ,
999
REPAIR KIT , FIRST EXHAUST STOCK OF OLD PARTS ON KNORR VALVE SV 1280-I/69324, Replaced By: A0003201067
999
REPAIR KIT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 957391, Replaced By: A0003200267
999
REPAIR KIT CONTROL VALVE KNORR SV 3111-I/73100,K 186867
999
OPERATING PLATE
999
CUP 3/2-WAY VALVE WABCO
999
VALVE BODYTO 002 429 95 44
999
VALVE , Replaced By: A0004291182
999
VALVE , Replaced By: A0004290782
999
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
GASKETTO 003 429 22 44
999
VALVE SEAT RINGWABCO,5 433388
999
BUSHINGWABCO,5 433388
999
JOINT (CENTRAL JOINT) TO 658 350 00 05,EHRENREICH
999
JOINT (CENTRAL JOINT) TO 393 350 54 05,LEMFOERDER
999
JOINT (CENTRAL JOINT) TO 393 350 55 05,EHRENREICH
999
REPAIR KIT. JOINT WITH BALL PIVOT
999
PROTECTIVE CAP , Replaced By: A0003290092
999
PROTECTIVE CAPTO 000 329 04 25,000 329 08 25,K 186867
999
BOOT ,5 292411
999
BOOT
999
BOOT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 957391, Replaced By: A0003280292
999
BOOT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 957391, Replaced By: A0003280292
999
BOOT ,4 809255
999
PROTECTIVE CAP ,4 809255
999
SPACER RINGTO 002 323 86 00,003 323 03 00,
999
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
999
SPACER TUBE , Replaced By: A0003232550
999
REPAIR KIT AIR SPRING VALVE
999
REPAIR KIT CONTROL VALVE KNORR SV 3111-I/83153,K 186867
999
REPAIR KIT AIR SPRING VALVE
999
VALVETO 000 329 04 25,000 329 08 25,K 186867
