Поз.
Артикул
Описание
4
ACCELERATOR PEDAL , Replaced By: A6243000304
4
ACCELERATOR PEDAL , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6243000304
4
LEVER , Replaced By: A3813000104
4
ACCELERATOR PEDAL , Replaced By: A3813000104
5
ACCELERATOR PEDAL (PARTS KIT), RANGE OF DELIVERY INCLUDES: 1X 655 301 00 93, 3X 000965 006077
8
SCREW ACCELERATOR PEDAL
12
BALL PIVOT LOAD SENSOR
12
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
16
NUT PUMP TO BRACKET
16
NUT , Replaced By: N913004006001
20
SHIM ACCELERATOR PEDAL
20
SHIM , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 859957, Replaced By: A6153010084
20
SHIM ,4 227107-4 604519, Replaced By: A3813010284, +001A3813010297
20
SHIM ,4 227106, Replaced By: A3813010284, +001A3813010297
24
BOOT ACCELERATOR PEDAL
24
BOOT ACCELERATOR PEDAL,4 859957
24
BOOT ,4 227107-4 604519, Replaced By: A3813010297, +001A6153010084
24
BOOT ,4 227106, Replaced By: A3813010297, +001A6153010084
28
SCREW ACCELERATOR PEDAL TO CAB M 6X25
30
SCREW PEDAL TO CAB FLOOR
32
SCREW VALVE TO BRACKET
32
SCREW VALVE TO BRACKET, Replaced By: N304014008002
36
NUT
38
STOP ACCELERATOR PEDAL
75
ROD LOAD SENSOR CONTROL
75
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER, 415 5 014668 416 5 000515 417 4 972023
75
ROD , Replaced By: A3604302992
80
BALL SOCKET PULL ROD TO LEVER
80
BALL SOCKET , Replaced By: A0009912422
85
NUT BALL PIVOT TO LEVER
89
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
144
MANUAL CONTROL IDLING ADJUSTMENT
148
KNOB MANUAL CONTROL
148
KNOB , Replaced By: A6153020001
152
FITTED WASHER MANUAL CONTROL
152
LOCK , Replaced By: N000988030003
156
NUT MANUAL CONTROL
160
WIRE CABLE IDLING ADJUSTMENT
160
WIRE CABLE IDLING ADJUSTMENT
160
WIRE CABLE MANUAL CONTROL
164
BRACKET
164
BRACKET , Replaced By: A3813020240
168
GROMMET
168
GROMMET , Replaced By: A3833020091
999
CLAMP , Replaced By: N916016008200
999
CLAMP , Replaced By: A3604300143
999
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
GUIDE MANUAL CONTROL
999
BALL SOCKET ROD TO ACCELERATOR PEDAL
999
BRACKET CABLE,4 345193
999
BALL SOCKET ROD TO BALL PIVOT
999
PAD ACCELERATOR PEDAL
999
GUIDE RAIL ACCELERATOR PEDAL TO FLOOR PLATE
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW , Replaced By: N304017006020
999
SCREW , Replaced By: N304017008021
999
SCREW GUIDE RAIL RETROFIT M 6X35, BORE THREADED HOLES IN CAB FLOOR TO 6.5MM
999
SHEET METAL SCREW , Replaced By: N914031005208
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW PIPE CLAMP
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
999
COMBINATION BOLT BRACKET TO WINDOW SILL GIRDER
999
CLAMP ,K 147121, Replaced By: N000000000319
