Поз.
Артикул
Описание
15
SUPPORT BATTERY/APPARATUS SUPPORT
15
SUPPORT BATTERY, 974675
16
SCREW BRACKET TO CAB CONSOLE,K 035197
16
SCREW , Replaced By: N000961014064
16
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
16
SCREW BRACKET TO SIDE MEMBER
17
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
17
PLATE , Replaced By: N000125015013
17
WASHER , Replaced By: N000125015019
18
NUT , Replaced By: N910113014001
18
NUT BRACKET TO SIDE MEMBER
33
PROTECTIVE PLATE BATTERY SUPPORT
33
PROTECTIVE PLATE AT SUPPORT, 974675
34
BRACKET PROTECTIVE PLATE TO APPARATUS SUPPORT, 415 5 014668 416 5 000515 417 4 972023
34
HOOD FASTENER BATTERY CASE,RB037929
34
BRACKET , Replaced By: A3874260040
35
PIN BRACKET TO BATTERY CASE, 415 5 014668 416 5 000515 417 4 972023
36
COTTER PIN BRACKET TO SUPPORT
58
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
58
NUT IN CASE OF SUBSEQUENT INSTALLATION
58
NUT BALL PIVOT TO LEVER
58
NUT , Replaced By: N304032005005
59
LOCK WASHER T-FITTING TO BRACKET
60
SPRING WASHER ALTERNATOR CONNECTION D+
60
SPRING WASHER LICENSE PLATE TO BRACKET
63
NEG. CABLE FROM FRAME CROSS MEMBER TO CAB
63
NEG. CABLE , Replaced By: A6205402339
64
GROMMET5.0 MM
65
HORN LOW NOTE BOSCH
65
HORN , Replaced By: A0045424420
65
SCREW , Replaced By: N304017008034
65
SCREW BRACKET TO CROSS CONNECTION STRUT
66
SCREW , Replaced By: N304017008016
66
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
67
WASHER , Replaced By: N000125008443
67
WASHER EXHAUST MUFFLER TO STRAP
68
NUT , Replaced By: N913004008001
68
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
BLIND CAP TACHOGRAPH LEAD SEALING,4 895864
999
DIAGRAM PAPER SET100 PIECES
999
DIAGRAM PAPER SET100 PIECES
999
GROMMET LINE THRU FRAME
999
BRACKET FLEXIBLE SHAFT,4 133594
999
CABLE HARNESS , ON SUBSEQUENT INSTALLATION OF 001 542 48 16 TACHOMETER
999
ELECTRIC CABLE ,4 231689
999
ELECTRIC CABLE INDUCTIVE PICKUP
999
BRACKET
999
ELECTRIC CABLE IDLING SWITCH BRANCH-OFF EXTENSION
999
TOOTHED WASHER STOP LIGHT SWITCH TO PEDAL BEARING BRACKET
