Поз.
Артикул
Описание
280
PLASTIC PIPE RISING PIPE 4X6 MM
280
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
281
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
282
INSULATING HOSE6 X 0.6 MM, ORDER BY THE METER
284
SLEEVE LEAK LINE
284
BUSHING , Replaced By: N915062004000
284
BUSHING , Replaced By: N915062004000
285
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
293
SEAL CONE
293
GLAND , Replaced By: A0019901667
297
BANJO UNION , Replaced By: N915052004006
297
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
302
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
304
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
308
SEAL RING LINE CONNECTION
312
CLAMP LINE MOUNTING
319
VALVE GEAR-CLUSTER/SHIFT-PATH INTERLOCK, 002,006 FROM CHASSIS 4 263014-4 422632, 034,134 FROM CHASSIS 4 276784-4 422632, 033 FROM CHASSIS 4 422632
319
VALVE , Replaced By: A0002608157
320
REPAIR KIT SOLENOID VALVE HERION,9417237/0734/12V
320
REPAIR KIT SOLENOID VALVE HERION,9417232/0711/12V
323
BRACKET SOLENOID VALVE,4 411810
324
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
324
SCREW , Replaced By: N304017006012
325
NUT , Replaced By: N913004006001
325
NUT PUMP TO BRACKET
326
SPACER RING BRACKET TO REAR AXLE HOUSING,5 244591
327
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
328
SCREW BRACKET TO TRANSMISSION,4 411810
353
SEAL RING VALVE TO VALVE,K 025179
353
SEAL RING SWITCH TO CASE COVER
353
SEAL RING , Replaced By: N007603018100
361
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.60 MM
361
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.00 MM
361
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 1.60 MM
361
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.20 MM
361
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.80 MM
361
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 3.00 MM
361
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 2.40 MM
361
SEAL RING IDLE POSITION SWITCH TO THREADED BUSHING, AS REQUIRED 1.80 MM
371
SWITCH
371
SWITCH , Replaced By: A0015455709
371
SWITCH , Replaced By: A0015458214
377
SWITCH , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 360728, Replaced By: A0005457909
377
SWITCH , Replaced By: A0005459009
377
SWITCH , Replaced By: A0015451109
377
SWITCH , Replaced By: A0015452709
377
SWITCH TORQUE REDUCER
381
PIN NEUTRAL POSITION
385
THREADED BUSHING NEUTRAL POSITION
389
SEAL RING NEUTRAL POSITION
393
SWITCH GEAR CLUSTER INDICATION
393
SWITCH , Replaced By: A0025458114
393
SWITCH , Replaced By: A0035451614
999
HOLLOW SCREW , Replaced By: N915047008100
999
BANJO UNION , Replaced By: N915052006013
999
REPAIR KIT SHIFT LEVER VALVE
999
T-FITTING EXHAUST-BRAKE POWER CYLINDER
999
SEAL RING OUTSIDE WABCO
999
FITTING , Replaced By: A0039979072
999
LOOM TIE , Replaced By: A0019978390
999
LOOM TIE LINE MOUNTING 280 MM
999
LOOM TIE LINE MOUNTING
999
FITTING (PARTS KIT),LINE RUPTURE
999
TS DOUBLE FITTING SOLENOID VALVE
999
FITTING , Replaced By: A0029905971
999
FITTING , Replaced By: A0029906071
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
SEAL RING ,4 411810
999
SEAL RING PISTON RINGS WABCO
999
SEAL RING SCREW FITTING WABCO
999
WASHER BRACKET TO TRANSMISSION
999
SHAFT SHIFTING TUBE TO TRANSMISSION
999
WASHER , Replaced By: A3029902040
999
BRACKET TOP RIGHT
999
BRACKET BOTTOM RIGHT
999
BUSHING PAWL TO ROD END,5 443048
999
BUSHING PAWL TO ROD END,5 443048
999
LOCK NUT SPEEDOMETER DRIVE COVERING
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
SCREW , Replaced By: N304017006018
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING PNEUMATIC VALVE
999
SHEET METAL SCREW
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
SPRING WASHER SHIFTING ROD TO SHIFT LEVER
999
HOLLOW SCREW LINE CONNECTION
999
HOLLOW SCREW LINE CONNECTION
999
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
