Поз.
Артикул
Описание
22
TANK AT CAB REAR PANEL, 415 5 014668 416 5 000515 417 4 972023
22
TANK
22
TANK , Replaced By: A3815000849
30
RADIATOR CAP
30
RADIATOR CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0005014215
30
RADIATOR CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0005014215
31
RADIATOR CAP
32
RADIATOR CAP FILLER NECK
32
RADIATOR CAP FILLER NECK
33
GASKET O.D., 52 MM
34
GASKET O.D., 37 MM
37
BRACKET EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
37
BRACKET EXPANSION TANK
37
BRACKET , Replaced By: A6155010020
41
SCREW BRACKET TO SIDE MEMBER
41
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
42
WASHER BRACKET TO RIGHT FENDER, 415 5 014668 416 5 000515 417 4 972023
43
NUT STRAP TO BRACKET
43
NUT , Replaced By: N910113010000
44
BRACKET (STRAP), 415 5 014668 416 5 000515 417 4 972023
44
BRACKET EXPANSION TANK
44
BRACKET , Replaced By: A3815012720
46
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
46
PAD , Replaced By: A3634750220
47
SHIM STRAP, 415 5 014668 416 5 000515 417 4 972023
47
SHIM , Replaced By: A3815010495
47
SHIM , Replaced By: A3815010295
50
SCREW END PIECE TO EXHAUST PIPE M 10X25
51
NUT STRAP TO BRACKET
51
NUT , Replaced By: N910113010000
52
WASHER RADIATOR TO RUBBER MOUNTING
52
WASHER , Replaced By: N000125010532
118
CONNECTOR
123
GASKET CONNECTOR, Replaced By: A0002011080
123
GASKET , Replaced By: A4422010480
126
SCREW END PIECE TO EXHAUST PIPE M 10X25
132
SPRING WASHER STEERING COLUMN BRACKET TO CAB
136
HOSE FROM WATER PUMP TO EXPANSION TANK AND TO HEATING PIPE
140
COOLING WATER PIPE FROM WATER PUMP TO EXPANSION TANK 900 MM,960233, 10/20962189, 50/60 FOR USE WITH MERCEDES-BENZ CAB
140
COOLING WATER PIPE FROM WATER PUMP TO EXPANSION TANK 890 MM,960232, 10/20962188, 50/60 FOR USE WITH MERCEDES-BENZ CAB
146
HOSE FROM WATER PUMP TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023 FOR USE WITH SHORT MERCEDES-BENZ CAB
146
HOSE , Replaced By: A3875011782
150
CLAMP
150
CLAMP
150
CLAMP , Replaced By: N000000000670
151
CLAMP25-40X13 MM
151
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
152
BRACKET COOLING WATER LINE TO FRAME
152
BRACKET , Replaced By: A3834929141
156
CLAMP COOLING WATER LINE TO BRACKET,5 022370
158
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
158
SCREW , Replaced By: N304017008016
160
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
160
NUT , Replaced By: N913004008001
162
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
162
BRACKET TRAILER PLUG SOCKET
166
CLAMP COOLING WATER LINE TO BRACKET,5 022370
168
SCREW PIPE CLAMP
168
SCREW , Replaced By: N304017008021
170
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
170
NUT , Replaced By: N913004008001
999
BRACKET , Replaced By: A3604292940
999
RADIATOR , Replaced By: A3875002903
