Поз.
Артикул
Описание
3
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
3
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
3
HOSE , Replaced By: A0009872827
6
SLEEVE LINE CONNECTION
6
BUSHING , Replaced By: N915062009000
9
SEAL CONE LINE CONNECTION
9
GLAND , Replaced By: A0019901967
12
UNION NUT LINE CONNECTION, Replaced By: N000000006239
12
UNION NUT LINE CONNECTION
15
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
15
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
18
SLEEVE LINE CONNECTION
18
SLEEVE , Replaced By: N915062006000
21
GLAND LINE CONNECTION
24
UNION NUT LINE CONNECTION
27
BANJO UNION HEATING CONNECTION,K 169122
27
BANJO UNION , Replaced By: N915052006005
39
LOOM TIE LINE MOUNTING
39
LOOM TIE LINE MOUNTING 280 MM
54
SUPPORT TWO-CIRCUIT BRAKE LINE COUPLING
54
SUPPORT TWO-CIRCUIT BRAKE LINE COUPLING, Replaced By: A3874321016
57
SUPPORT BRAKE LINE COUPLINGS
57
SUPPORT , Replaced By: A6214320116
57
SUPPORT , Replaced By: A3874321616
57
SUPPORT , Replaced By: A3874320916
60
ANGLE RIGHT
60
ANGLE , Replaced By: A6214320117
60
ANGLE LEFT
60
ANGLE , Replaced By: A6214320017
63
SCREW PIPE CLAMP
63
SCREW , Replaced By: N304017008021
66
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
69
WASHER EXHAUST MUFFLER TO STRAP
69
WASHER , Replaced By: N000125008443
72
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
72
NUT , Replaced By: N913004008001
75
NUT STRAP TO BRACKET
75
NUT , Replaced By: N910113010000
78
BRAKE VALVE TRAILER CONTROL VALVE, FROM CHASSIS 4 375194-4 412020 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
78
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313505
78
BRAKE VALVE TRAILER CONTROL VALVE WABCO,4 375193
78
BRAKE VALVE , Replaced By: A0014313705
78
BRAKE VALVE TRAILER CONTROL VALVE BOSCH,4 375193 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
84
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0034313405
84
BRAKE VALVEWABCO, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
87
BRAKE VALVE (TRAILER CONTROL VALVE) KNORR, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
87
BRAKE VALVEGRAU, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
87
BRAKE VALVE , IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING, Replaced By: A0024314005
87
BRAKE VALVE (TRAILER CONTROL VALVE) KNORR, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
87
BRAKE VALVE , Replaced By: A0024314805
90
BRAKE VALVE (TRAILER CONTROL VALVE) KNORR,4 412021
90
BRAKE VALVE , Replaced By: A0024314905
90
BRAKE VALVE (TRAILER CONTROL VALVE) BOSCH,4 412021 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
90
BRAKE VALVE (TRAILER CONTROL VALVE) WABCO,4 412021 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
93
BRAKE VALVE (TRAILER CONTROL VALVE) GRAU,4 412021
96
VALVE SEATTO 001 431 74 05,GRAU 355 029 001
99
VALVE SEATTO GRAU
99
VALVE SEATTO GRAU
102
GASKET34X2X6 MM,GRAU
102
GASKETTO 001 431 73 05.001 431 74 05,4 412021
105
SEAL RING64.77X2.62,TO GRAU
105
SEAL RING64.77X2.62,TO GRAU
105
SEAL RING64.77X2.62,TO GRAU
105
SEAL RING64.77X2.62,TO GRAU
105
SEAL RING64.77X2.62,TO GRAU
105
SEAL RING64.77X2.62,TO GRAU
105
SEAL RING64.77X2.62,TO GRAU
105
SEAL RING64.77X2.62,TO GRAU
108
SEAL RING18X2.5,TO GRAU
108
SEAL RING18X2.5,TO GRAU
111
SEAL RING44.2X3,TO GRAU
111
SEAL RING44.2X3,TO GRAU
114
SEAL RING30X2,TO GRAU
114
SEAL RING30X2,TO GRAU
117
SEAL RING7X1.5,TO GRAU
117
SEAL RING7X1.5,TO GRAU
117
SEAL RING7X1.5,TO GRAU
120
SEAL RING21.3X2.4 TO 001 431 74 05,
120
SEAL RING21.3X2.4 TO 001 431 74 05,
120
SEAL RING22.3X2.4 MM,GRAU
120
SEAL RING21.3X2.4 TO 001 431 74 05,
123
SEAL RING90X3,TO GRAU
123
SEAL RING90X3,TO GRAU
126
SEAL RING100X3,TO GRAU
126
SEAL RING100X3,TO GRAU
129
SEAL RING39.2X3 TO 001 431 74 05,
129
SEAL RINGTO GRAU
132
SEAL RING9X1.5,TO GRAU
132
SEAL RING9X1.5,TO GRAU
132
SEAL RING9X1.5,TO GRAU
135
SEAL RING23.47X2.62,TO GRAU
135
SEAL RING23.47X2.62,TO GRAU
138
REPAIR KIT , Replaced By: A0014304760
138
REPAIR KITTO 001 431 67 05, BOSCH 061 010
138
REPAIR KIT VALVE DISC TO 001 431 67 05,BOSCH 061 214
138
GASKET KIT SEAL RING TO 001 431 67 05,BOSCH 061 214
138
REPAIR KIT , Replaced By: A0004301109
138
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
138
REPAIR KIT , Replaced By: A0024301860
138
REPAIR KITTO WABCO
138
REPAIR KITTO KNORR
138
REPAIR KITTO KNORR
138
REPAIR KIT VALVE SEAT KNORR
138
REPAIR KITTO GRAU
153
T-FITTING
156
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
156
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
156
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
159
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
159
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
159
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
162
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
162
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
162
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
165
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
165
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
165
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
165
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
165
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
165
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
165
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
168
FITTING , Replaced By: A0029979572
168
FITTING RELAY VALVE,CONNECTION: "40",5 359430
168
FITTING RELAY VALVE,CONNECTION: "40",5 359430
168
FITTING RELAY VALVE,CONNECTION: "40",5 359430
168
FITTING RELAY VALVE,CONNECTION: "40",5 359430
168
FITTING RELAY VALVE,CONNECTION: "40",5 359430
168
FITTING RELAY VALVE,CONNECTION: "40",5 359430
171
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3874300710
171
BRACKET TRAILER CONTROL VALVE
174
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3894300010
174
BRACKET , Replaced By: A3894300110
174
BRACKET ,4 667210
174
BRACKET ,4 667210
177
BRACKET , Replaced By: A6205244040
177
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
177
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
180
GUIDE BUSHING TWO-WAY VALVE TO FRAME
180
SPACER TUBE , Replaced By: A3094310249
183
SCREW PIPE CLAMP
183
SCREW PIPE CLAMP
183
SCREW , Replaced By: N304017008021
186
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
186
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
186
SCREW , Replaced By: N304017008027
186
SCREW PIPE CLAMP
186
SCREW , Replaced By: N304017008021
189
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
189
SCREW , Replaced By: N304017008028
189
SCREW SUPPORT TO FENDER
189
SCREW , Replaced By: N304017008018
192
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
192
NUT , Replaced By: N913004008001
216
FITTING DELIVERY LINE TO PUMP
216
FITTING DELIVERY LINE TO PUMP
216
FITTING DELIVERY LINE TO PUMP
219
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
219
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
219
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
219
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
330
FITTING BRAKE LINE COUPLING TO BRACKET
333
NUT BRACKET TO SIDE MEMBER
336
TEST CONNECTION
336
TEST CONNECTION , Replaced By: A0004312931
337
PLUG
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE HAND BRAKE VALVE WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
SPRINGWABCO,002 0,012 0
999
PLUG FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
FITTING , Replaced By: A0019972572
999
FITTING CONNECTION "4"
999
BRACKET ,4 412020
999
PLUG TWO-CIRCUIT BRAKE VALVE,CONNECTIONS: "21,22", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
