Поз.
Артикул
Описание
3
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
7
UNION NUT LINE CONNECTION
11
GLAND LINE CONNECTION
19
ELBOW FITTING , Replaced By: A0039901671
19
ELBOW FITTING ENGINE AIR COMPRESSOR,CONNECTION: "20", Replaced By: A6209900071
21
NUT SUCTION LINE TO OIL PUMP
23
THRUST RING SUCTION LINE TO OIL PUMP
25
SEAL RING LINE CONNECTION
27
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
33
BRACKET COMPRESSED AIR LINE TO ENGINE
41
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
41
CLAMP LINE MOUNTING
41
CLAMP , Replaced By: A6739950001
41
CLAMP DELIVERY AND SUCTION LINES TO STEERING
43
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
45
SCREW CLAMP TO BRACKET
47
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
49
NUT PUMP TO BRACKET
999
REPAIR KITTO 001 430 18 81/78 81
