Поз.
Артикул
Описание
2
CROSS MEMBERNR. 09
3
RIVET FRAME TRUSS TO SIDE MEMBER
4
HYDRAULIC BRAKEVOITH, ON VEHICLES HAVING DAIMLER -BENZ FROM IDENT NO.:046311,ON VEHICLES HAVING NO DAIMLER -BENZ BODY FROM IDENT NO.:046237 ALSO INSTALLED ON 045222,045251 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
SCREW PLUG OIL FILLING
8
SCREW PLUG , Replaced By: N007604030101
20
SEAL RING OIL FILLING AND OIL DRAIN
24
SEAL RING HOUSING 115X140X10 MM
26
SEAL RING , Replaced By: A0004380560
26
SEAL RING , Replaced By: A0004380660
26
SEAL RING HOUSING 120X112X4.5 MM
27
SEAL RING HOUSING 196.52X2.62 MM
28
SOLENOID24V
32
SEAL RING SOLENOID 19X2.5 MM
36
RADIATOR
36
RADIATOR , Replaced By: A0015017101
36
RADIATOR , Replaced By: A0005000201
37
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
38
WASHER RADIATOR TO RUBBER MOUNTING
38
WASHER , Replaced By: N000125010532
39
STUD , Replaced By: A0019900505
39
STUD RADIATOR
40
NUT STRAP TO BRACKET
40
NUT , Replaced By: N910113010000
41
SCREW REAR EXHAUST PIPE TO MUFFLER
41
SCREW RADIATOR M 10X45
42
SEAL RING RADIATOR 36X4 MM
43
SEAL RING RADIATOR 18X3 MM
44
WASHER RADIATOR
45
SEAL RING CONTROL VALVE 10X3 MM
48
SEAL RING CASE COVER 297X4 MM
52
SEAL RING CONTROL VALVE 60X4 MM
60
SEAL RING12X18
68
VALVE , Replaced By: A0015403497
68
VALVE CONTROL VALVE
78
VALVE , Replaced By: A0034304181
80
VALVE , Replaced By: A0034302481
80
VALVE , Replaced By: A0034304281
82
GASKET , Replaced By: A0004380680
82
GASKET78X78X0.5 MM
84
VALVE , Replaced By: A0034304281
84
VALVE , Replaced By: A0034304181
84
VALVE
88
SEAL RING BLEEDING
90
SCREW BRACKET TO CROSS CONNECTION STRUT
90
SCREW , Replaced By: N304017008034
91
WASHER , Replaced By: N000125008443
91
WASHER EXHAUST MUFFLER TO STRAP
93
SCREW PLUGM 12X1.5
94
SEAL RING
96
COVER (HINGED COVER), NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
96
COVER , Replaced By: A0004380414
100
VALVE , Replaced By: A0004381281
100
VALVE
104
SEAL RING40X47 MM
106
SCREW ROTOR
106
SCREW , Replaced By: A0004381371
108
SCREW PLUG , Replaced By: N000908022011
108
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
109
BRACKET LOCKING VALVE
109
LINE , Replaced By: A0004380040
112
SEAL RING LOCKING VALVE 22X29 MM
116
GASKET LOCKING VALVE 15X2 MM
120
SCREW SOLENOID
124
SEAL RING6X2 MM
128
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 27X1
128
PLUG , Replaced By: A3805402281
131
SCREW OIL DRAIN M 30X1.5
132
SEAL RING OIL DRAIN 30X36 MM
133
LOCK SCREW
134
WASHER AS REQUIRED 3.50 MM,TO 000 430 06 95,12 95
134
WASHER AS REQUIRED 3.10 MM
134
WASHER AS REQUIRED 3.30 MM,TO 000 430 06 95,12 95
134
WASHER AS REQUIRED 2.50 MM,TO 000 430 06 95,12 95
134
WASHER AS REQUIRED 2.70 MM
134
WASHER AS REQUIRED 2.90 MM
141
SCREW FLANGE TO SHAFT M 12X210
999
REPAIR KIT LOCKING VALVE
999
HYDRAULIC BRAKE"VOITH", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
GASKET KIT RETARDER
999
FLANGE TELMA BRAKE
999
SEAL RING FLANGE
999
COVER (HINGED COVER)
999
FLANGE
999
VALVE (FLOAT HOLLOW BALL)
999
WASHER AS REQUIRED 1,6 MM
999
WASHER AS REQUIRED 1.8 MM
999
WASHER AS REQUIRED 2,0 MM
999
FLANGE
999
WASHER AS REQUIRED 2.2 MM
999
SCREW OIL FILLING
999
WASHER AS REQUIRED 2.6 MM
999
SCREW HOUSING
999
SCREW OIL FILLING
999
MOLDED PIECE
999
RING , Replaced By: A0009911045
999
RING ROTOR
999
REPAIR KIT CONTROL VALVE
999
STUD FLANGE TO EDDY CURRENT BRAKE
999
SCREW FLANGE TO TRANSMISSION CASE COVER
999
SCREW FLANGE TO TRANSMISSION CASE COVER M 10X25
999
VALVE , Replaced By: A0034304181
999
SCREW ON TRANSMISSION END
999
SEAL RING95X4.5 MM
999
SEAL RING62X4 MM
999
SEAL RING HOUSING
999
SEAL RING RADIATOR
999
SCREWM 6X16
999
RUBBER MOUNTING , Replaced By: A3572400218
999
RUBBER MOUNTING ENGINE REAR SUSPENSION
999
RUBBER MOUNTING ENGINE REAR SUSPENSION
999
RUBBER MOUNTING , Replaced By: A3572400318
999
RUBBER MOUNTING ENGINE REAR SUSPENSION
999
RUBBER MOUNTING ADJUSTABLE,FRONMT
999
CROSS MEMBERNO.10
999
FRAME
999
SHIM BEARING BRACKET TO SIDE AND CROSS MEMBERS
999
ANGLE LEFT
999
ANGLE RIGHT
999
WASHER , Replaced By: N000433010510
999
WASHER VIBRATION ABSORBER TO BRACKET
999
SCREW CONTROL VALVE
999
SCREW
999
SCREW , Replaced By: N308676014012
999
SCREW MOUNTING TO CONSOLE M 14X55
999
SEAL RING OIL FILLING AND OIL DRAIN
999
SCREWM 6X25
999
SCREW , Replaced By: A1249900520
999
SCREW SUPPORT TO SIDE MEMBER M 14X45
999
NUT STEERING SUPPORT TO FRAME
999
NUT , Replaced By: N910113014000
