Поз.
Артикул
Описание
5
STEERING WHEEL ,K 072836 IINO.7B90 III
8
NUT STEERING WHEEL TO STEERING COLUMN
11
BADGE STEERING WHEEL,K 072836 IINO.7B90 III
14
BEARING STEERING SHAFT
17
STEERING SHAFT
20
NEEDLE BEARING
23
BALL BEARING
23
BALL BEARING
26
COVER
29
COVER
32
WASHER
35
LOCK RING
38
LOCK RING
41
HANDLE , Replaced By: A6754600369
44
THRUST PLATE STEERING WHEEL HEIGHT ADJUSTMENT,4 727154
44
THRUST PLATE LEFT HANDLE
47
DOWEL PIN STEERING WHEEL TILT ADJUSTMENT,4 188879
50
HEADLESS SETSCREW LEFT HANDLE
53
HANDLE , Replaced By: A6554600469
56
ROLL PIN. CLAMPING SLEEVE BRACKET TO STEERING COLUMN END
59
THRUST PLATE
62
DISC SPRING STEERING WHEEL TILT ADJUSTMENT,4 231946-4 430729
65
GUIDE , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO. 4 430730 - 5 468371, Replaced By: A3834600136
68
SCREW GUIDE TO STEERING COLUMN END
71
STEERING COLUMN BRACKET ADJUSTABLE STEERING COLUMN,4 430730
74
RUBBER PAD ADJUSTABLE STEERING COLUMN TO 383 460 09 31
77
SCREW WASHER TO STEERING COLUMN BRACKET M 5X12,4 231946
80
WASHER ADJUSTABLE STEERING COLUMN
83
PLUG STEERING COLUMN END,5 0627235 113997
83
PLUG TOP,5 220080
86
PIN STEERING COLUMN BRACKET TO STEERING COLUMN END
87
STEERING SHAFT STEERING
87
STEERING SHAFT , Replaced By: A6824607409
87
STEERING SHAFT
87
STEERING SHAFT
90
RING STEERING SHAFT
92
UNIVERSAL JOINT STEERING SHAFT TO STEERING, MECHANIC STEERING-762.0
92
UNIVERSAL JOINT STEERING SHAFT TO STEERING, MECHANIC STEERING-762.0
92
UNIVERSAL JOINT STEERING SHAFT TO STEERING, MECHANIC STEERING-762.0
92
UNIVERSAL JOINT , Replaced By: A3444607157
92
UNIVERSAL JOINT , Replaced By: A3444607157
95
SCREW UNIVERSAL JOINT TO STEERING COLUMN TO 382 460 70 57
95
SCREW STEERING SHAFT TO STEERING
95
SCREW UNIVERSAL JOINT TO STEERING COLUMN M 8X38,5 463984
98
SCREW STEERING SHAFT TO STEERING M 8X42
101
NUT BRACKET TO SIDE MEMBER
104
FLANGE STEERING COLUMN JACKET TUBE TO FLOOR PLATE
107
PROTECTIVE SLEEVE
110
TAPPING SCREW. SHEET METAL SCREW ,D 091466
131
STEERING COLUMN END ADJUSTABLE STEERING COLUMN,4 727154
134
BUSHING STEERING COLUMN BRACKET
146
BUSHING STEERING COLUMN BRACKET TO WINDOW SILL
147
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
149
SCREW CROSS MEMBER TO SIDE MEMBERS
149
SCREW CLAMPING BOLT TO BRACKET
999
SPACER WASHER AS REQUIRED 0.05MM,TO 382 460 72 25
999
SPACER WASHER AS REQUIRED 0.08MM,TO 382 460 72 25
999
SPACER WASHER AS REQUIRED 0.12MM,TO 382 460 72 25
999
SPACER WASHER AS REQUIRED 0.16MM,TO 382 460 72 25
999
SPACER WASHER AS REQUIRED 0.20MM,TO 382 460 72 25
999
SPACER WASHER AS REQUIRED 0.24MM,TO 382 460 72 25
999
SPACER WASHER AS REQUIRED 0.28MM,TO 382 460 72 25
999
SPACER WASHER AS REQUIRED 0.32MM,TO 382 460 72 25
999
SPACER WASHER AS REQUIRED 0.36MM,TO 382 460 72 25
999
BEVEL GEARTO.382 460 72 25
999
LOCK RING AS REQUIRED 1.90MM, TO 382 460 72 25
999
LOCK RING AS REQUIRED 1.94MM, TO 382 460 72 25
999
LOCK RING AS REQUIRED 1.98MM, TO 382 460 72 25
999
LOCK RING AS REQUIRED 2.02MM, TO 382 460 72 25
999
LOCK RING AS REQUIRED 2.06MM, TO 382 460 72 25
999
LOCK RING AS REQUIRED 2.10MM,TO 382 460 72 25
999
LOCK RING AS REQUIRED 2.14MM, TO 382 460 72 25
999
BOOT , NOT USED
999
SEAL RING MITER GEARING TO 382 460 72 25
999
SEAL RING MITER GEARING TO.382 460 72 25
999
DOWEL PINTO.382 460 72 25
999
SPACER WASHER AS REQUIRED 0.40MM, TO 382 460 72 25
999
BOXTO 382 460 72 25
999
NEEDLE BEARING DIFFERENTIAL PINION BEARING TO 382 460 72 25
