Поз.
Артикул
Описание
3
CYLINDER , Replaced By: A0015539505
3
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING POWER PACKER,4 733732
3
CYLINDER , Replaced By: A0015533605
3
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING WEBER
3
CYLINDER , Replaced By: A0015533505
3
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING POWER PACKER,4 733732
3
CYLINDER , Replaced By: A0015533605
7
GUIDETO 001 553 49 05
30
GASKET KIT HYDRAULIC CYLINDER TO 000 553 03 05,000 553 18 05,
30
GUIDE , Replaced By: A0015534905
30
REPAIR KIT , Replaced By: A0005501535
35
GASKET KIT HYDRAULIC CYLINDER POWER PACKER
40
BEARING BRACKET HYDRAULIC CYLINDER
45
SCREW MOUNTING TO CONSOLE
45
SCREW BRACKET TO SPRING BRACKET AND TO CROSS MEMBER,5 953233K 027550
50
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
60
BUSHING HYDRAULIC CYLINDER TO BEARING BRACKET
62
COTTER PIN6,3X36 MM
64
WASHER HYDRAULIC CYLINDER TO CAB
68
WASHER HYDRAULIC CYLINDER TO CAB
72
WASHER HYDRAULIC CYLINDER TO CAB
78
WASHER HYDRAULIC CYLINDER TO CAB
82
NUT TRAILER COUPLING TO REAR CROSS MEMBER M 16
82
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
90
PUMP (HAND PUMP) POWER PACKER
90
PUMP , Replaced By: A0005536501
90
PUMP (HAND PUMP) WEBER
90
PUMP , Replaced By: A0005537901
94
LEVERTO 000 553 37 01,000 553 39 01,WEBER
95
GASKETTO 000 553 23 01,000 553 37 01,
97
SNAP RINGWEBER,TO 000 553 40 01, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
98
SCREW OIL FILLING TO 000 553 89 01
100
PISTONTO 000 553 39 01,WEBER
100
PISTONTO 000 553 23 01,000 553 37 01,
102
VALVETO 000 553 39 01,WEBER
102
VALVETO 000 553 23 01,000 553 37 01,
102
VALVE , Replaced By: A0005501555
106
SEAL RINGTO 000 553 23 01,000 553 37 01,
110
SEAL RINGTO 000 553 23 01,000 553 37 01,
114
CLAMPING SLEEVE4X28 MM,TO 000 553 23 01,,4 250876
118
CLAMPING SLEEVE4X12 MM,TO 000 553 23 01,
122
SCREW , Replaced By: N000000000190
124
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
126
FILTER
130
BOOTTO 000 553 23 01,000 553 37 01,
132
SEAL RINGTO 000 429 59 30, KNORR
134
SEAL RING28.4X2.6 MM
135
FITTED WASHER
136
LOCK RING
138
SEAL RINGTO 000 553 37 01,000 553 39 01,WEBER,4 250876
141
GASKET KIT HAND PUMP TO 000 553 37 01,000 553 39 01,WEBER
141
GASKET KIT , Replaced By: A0005502583
144
REPAIR KIT VALVE TO 000 553 54 01,POWER-PACKER,4 733732
146
REPAIR KIT PISTON TO 000 553 54 01,POWER-PACKER,4 733732
150
BRACKET HAND PUMP
154
SCREW , Replaced By: N304017010002
158
NUT , Replaced By: N910113010000
162
SCREW SUPPORT TO SIDE MEMBER M14X40
162
SCREW , Replaced By: N308676014020
166
NUT , Replaced By: N910113014001
170
LINE FROM FITTING TO VALVE 6X1 MM, LENGTH AVAILABLE 3000 MM
172
HOSE FROM HYDRAULIC LINE TO CYLINDER
172
HOSE , Replaced By: A3875530182
174
UNION NUT
178
GLAND , Replaced By: A0019901667
186
UNION NUT
190
GLAND , Replaced By: A0019901667
194
BRACKET SUCTION LINE
198
ANGLE LINE MOUNTING
198
ANGLE , Replaced By: A3604280243
200
SCREW , Replaced By: N910142008009
200
SCREW , Replaced By: N304017008021
202
SCREW END PIECE TO EXHAUST PIPE M 10X25
204
NUT , Replaced By: N910113010000
210
NUT BRACKET TO BRACKET
210
NUT , Replaced By: N913004008001
214
CLAMP LINE MOUNTING
216
SCREW AT FILTER BRACKET
216
SCREW COVER PLATE TO BRACKET
220
NUT PUMP TO BRACKET
220
NUT , Replaced By: N913004006001
230
HOSE FROM HAND PUMP TO HYDRAULIC CYLINDER
234
UNION NUT
236
GLAND , Replaced By: A0019901667
250
FITTING 3/2-WAY VALVE,CONNECTION: "30"
250
SCREW-IN FITTING , Replaced By: A0029978472
250
FITTING , Replaced By: A0019909871
250
T-FITTING EXHAUST-BRAKE POWER CYLINDER
254
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
254
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
254
FITTING , Replaced By: A0019909871
256
SEAL RING LINE CONNECTION
262
LOOM TIE LINE MOUNTING
266
CLAMP ,K 147121, Replaced By: N000000000319
272
NUT PUMP TO BRACKET
272
NUT , Replaced By: N913004006001
