Поз.
Артикул
Описание
5
CABLE HARNESS TACHOGRAPH, DIESER LEITUNGSSATZ IST EIN TEIL DES KOMPLETTEN VARIANTENLEITUNGSSATZES UND KANN ALS ERSATZTEIL GELIEFERT WERDEN ACHTUNG: NUR WENN EIN KOMPLETTER VARIANTENLEITUNGSSATZ BENOETIGT WIRD,IST ER UNTER ANGABE DER IDENT-NR. ZU BESTELLEN
5
CABLE HARNESS CAB MAIN CABLE HARNESS, FROM IDENT NO. K 074703ALSO INSTALLED ON K 062141K 157828
5
CABLE HARNESS , Replaced By: A6555406905, +001A9425400136
5
CABLE HARNESS CAB MAIN CABLE HARNESS, FROM IDENT NO. K 074703ALSO INSTALLED ON K 062141K 157828
5
CABLE HARNESS CAB MAIN CABLE HARNESS, THIS CABLE HARNESS IS A COMPONENT OF FRAME MOUNTED CABLE HARNESS ASSEMBLY AND CAN BE MADE AVAILABLE AS A SPARE ATTENTION: WHEN PLACING ORDERS, PLEASE QUOTE VEHICLE IDENT NO. ONLY IF FRAME MOUNTED CABLE HARNESS IS REQUIRED AS AN ASSEMBLY COMPONENTS SEE CHASSIS PARTS KIT ACTROS DESIGN GROUP 54
8
BRACKET ELECTRIC CABLE THRU CAB FLOOR
11
SEAL ELECTRIC CABLE THRU CAB FLOOR
14
SEAL RING ELECTRIC CABLE THRU CAB FLOOR
17
SHEET METAL SCREW ELECTRIC CABLE THRU CAB FLOOR
17
TAPPING SCREW BRACKET TO CAB FLOOR
20
WASHER , Replaced By: N009021005205
23
LOCK ELECTRIC CABLE THRU CAB FLOOR
38
SCREW BRACKET MOUNTING M 6X20
41
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
44
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
47
SWITCH STOP LIGHT
50
TOOTHED WASHER STOP LIGHT SWITCH TO PEDAL BEARING BRACKET
53
NUT SWITCH
92
SHEET METAL SCREW CABLE MOUNTING IN CABLE DUCT, NOT USED
98
RUBBER RING ELECTRIC CABLE TO CABLE DUCT
999
LOCK WASHER PLUG SOCKET TO BRACKET,5 906887
999
SCREW PLUG SOCKET TO BRACKET
999
NUT PLUG SOCKET TO BRACKET,5 906887
999
ELECTRIC CABLE FROM CODING-PLUG PLUG-CONNECTION TO DIAGNOSIS PLUG SOCKET, UP TO IDENT NO. K 074702 EXCEPT FOR K 062141
