Поз.
Артикул
Описание
122
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
122
PLASTIC PIPE AERATION, ORDER BY THE METER
122
PLASTIC PIPE AERATION, ORDER BY THE METER
122
PLASTIC PIPE AERATION, ORDER BY THE METER
122
PLASTIC PIPE AERATION, ORDER BY THE METER
123
FITTING , Replaced By: A0029905971
123
FITTING (PARTS KIT),LINE RUPTURE
124
BANJO UNION HEATING CONNECTION,K 169122
520
RESERVOIR , Replaced By: A0014327501
532
O-RING CHECK VALVE TO AIR RESERVOIR
532
O-RING CHECK VALVE TO AIR RESERVOIR
532
O-RING CHECK VALVE TO AIR RESERVOIR
532
O-RING CHECK VALVE TO AIR RESERVOIR
532
O-RING CHECK VALVE TO AIR RESERVOIR
534
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
534
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
534
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
534
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
534
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
538
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
538
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
538
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
538
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
540
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
540
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
544
FITTING AIR RESERVOIR,CONNECTION: "13"
545
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
546
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
547
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
578
BRACKET AIR RESERVOIR TO FRAME
580
SCREW , Replaced By: A0069909301
580
SCREW , Replaced By: N910142008001
580
SCREW , Replaced By: N910143008002
582
NUT , Replaced By: N913004008001
589
STRAP AIR RESERVOIR III,5 088361
589
STRAP AIR RESERVOIR TO BRACKET
590
STRAP AIR RESERVOIR III,5 088361
590
STRAP AIR RESERVOIR III,5 088362
594
NUT , Replaced By: N910113010000
606
VALVE (CHECK VALVE) WABCO
606
VALVE (CHECK VALVE) SCHAEFER
606
VALVE (CHECK VALVE) VOSS
607
VALVE TAPPETTO 002 429 96 44,VOSS
608
SEAL RINGTO 002 429 96 44,VOSS
609
SEAL RING13.6X2 MM,TO 003 429 12 44,SCHAEFER
610
SEAL RING15.3X2.4 MM,TO 003 429 12 44,SCHAEFER
611
THRUST WASHERTO 003 429 12 44,SCHAEFER
612
SEAL CONETO 003 429 12 44,SCHAEFER
613
VALVETO 003 429 04 44,WABCO
614
SEAL RING19.3X2.4 MM,TO 003 429 04 44,WABCO
615
SEAL RING , Replaced By: N007603012121
616
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
617
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
618
HOLLOW SCREW LINE CONNECTION
619
SEAL RING LINE CONNECTION
620
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
622
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
624
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
628
SEAL RING FUEL LINE TO FEED PUMP
630
HOLLOW SCREW , Replaced By: N915036010108
634
BRACKET , Replaced By: A6164290140
634
BRACKET HEAT SHIELD
635
SCREW HAND PUMP TO BRACKET
636
NUT , Replaced By: N910113010000
638
NUT CHECK VALVE TO AIR RESERVOIR
