Поз.
Артикул
Описание
5
CROSS MEMBER FRONT
6
ANGLE LEFT
6
ANGLE RIGHT
8
ANGLE RIGHT
8
ANGLE LEFT
11
CROSS MEMBER (FRONT SPRING BRACKET),FRONT NO.2
14
ANGLE CROSS MEMBER TO SIDE MEMBERS
20
REAR SUBFRAME FRONT RIGHT,001317004068
23
PLATE HELPER SPRING
26
CONSOLE SHOCK ABSORBER TO SIDE MEMBER
26
BRACKET SHOCK ABSORBER TO SIDE MEMBER
29
CONSOLE ENGINE FRONT SUPPORT TO FRAME
32
SCREW BRACKET TO APPARATUS SUPPORT M 10X30
32
SCREW EXHAUST PIPE TO SIDE MEMBER
32
SCREW , Replaced By: N910105010001
32
SCREW HAND PUMP TO BRACKET
35
NUT , Replaced By: N910113010000
35
NUT EXHAUST PIPE TO SIDE MEMBER
38
CROSS MEMBER
41
CONSOLE LEFT FRONT SPRING REAR BRACKET
41
CONSOLE RIGHT FRONT SPRING REAR BRACKET
44
CONSOLE ENGINE RIGHT SUPPORT
44
CONSOLE ENGINE LEFT SUPPORT
47
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X30
47
SCREW EXHAUST PIPE TO BRACKET
47
SCREW BRACKET TO PROPELLER SHAFT BEARING HOUSING M 12X30
50
SCREW , Replaced By: N910105010009
53
NUT STRAP TO SUPPORT
53
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
53
NUT , Replaced By: N910113012003
56
NUT EXHAUST PIPE TO SIDE MEMBER
999
REAR SUBFRAME FRONT LEFT
