Поз.
Артикул
Описание
5
BEARING BRACKET (PEDAL BEARING BRACKET)
8
THREADED INSERT
11
STUD
14
GASKET BEARING BRACKET TO CAB
17
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
20
NUT BRACKET TO BRACKET
20
NUT , Replaced By: N913004008001
23
STOP CLUTCH PEDAL,5 219889
26
STOP BRAKE PEDAL
29
STOP CLUTCH PEDAL AND BRAKE PEDAL
32
STOP BRAKE PEDAL
35
SCREW , Replaced By: N304017006018
35
SCREW , Replaced By: N910105006023
38
PEDAL CLUTCH,5 219889
41
PAD , Replaced By: A1072910182
44
NEEDLE BEARING CLUTCH PEDAL
44
NEEDLE BEARING CLUTCH PEDAL
47
SPACER TUBE CLUTCH PEDAL
50
WASHER CLUTCH PEDAL TO BEARING BRACKET
53
PIN CLUTCH PEDAL TO BEARING BRACKET
56
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
59
SCREW AT FILTER BRACKET
59
SCREW , Replaced By: N304017006016
62
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
65
PIN CLUTCH PEDAL RESET
66
ROD CLUTCH PEDAL RESET
68
SPRING RETAINER CLUTCH PEDAL RESET
71
SPRING CLUTCH PEDAL RESET
74
SPRING RETAINER CLUTCH PEDAL RESET
77
NUT , Replaced By: N304035010001
80
LOCK PLATE RELEASE LEVER TO SHAFT
83
STOP CLUTCH PEDAL RESET,5 219889
86
WASHER , Replaced By: N000125010532
89
REPAIR KIT DEAD CENTER SPRING,5 219889
92
PEDAL BRAKE
95
PAD , Replaced By: A1072910182
98
BUSHING BRAKE PEDAL
98
BUSHING , Replaced By: A1242920050
101
PIN BRAKE PEDAL TO BEARING BRACKET
104
ROD TWO-CIRCUIT-BRAKE-VALVE CONTROL
107
YOKE OPERATING ROD,K 202311
110
NUT , Replaced By: N304035008001
113
PIN ROD TO BRAKE PEDAL
116
WASHER BRACKET TO CROSS MEMBER
119
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
122
SPRING BRAKE PEDAL RELEASE SPRING
