Поз.
Артикул
Описание
5
BEARING BRACKET CLUTCH, IN CASE OF PEDAL BEARING BRACKET WITH SHIMS,DELIVER ADDITIONALLY: 3X 000939 008136,1X 620 290 03 34 UP TO IDENT NO. 5 238024, SEE SERVICE INFORMATION 29/4
8
WASHER , Replaced By: N000125008443
11
STUD BOLT BRACKET TO CROSS MEMBER
14
NUT , Replaced By: N913004008001
14
NUT BRACKET TO BRACKET
17
STOP PEDAL ASSEMBLY
20
LOCK STOP TO BEARING BRACKET
20
LOCK RING , Replaced By: A0079942041
23
PEDAL CLUTCH PEDAL,4 915383
26
SPACER TUBE CLUTCH PEDAL
29
NEEDLE BEARING
32
PAD BRAKE
35
SPRING CLUTCH PEDAL RESET
38
PIVOT PIN PEDAL TO BEARING BRACKET
41
LOCK PEDAL TO BEARING BRACKET
44
SCREW , Replaced By: N910105006023
44
SCREW , Replaced By: N304017006016
47
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
50
LOCK RING
53
SPRING RETAINER SPRING TO PUSH ROD
56
SPRING (DEAD CENTER SPRING) 35 MM
59
SPRING RETAINER SPRING TO PUSH ROD
62
NEEDLE BEARING JOINT TO PIN
62
NEEDLE BEARING JOINT TO PIN
62
NEEDLE BEARING JOINT TO PIN
62
NEEDLE BEARING JOINT TO PIN
65
NUT PUSH ROD
68
WASHER BRACKET TO CROSS MEMBER
71
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
74
REPAIR KIT DEAD CENTER SPRING
