Поз.
Артикул
Описание
5
SHIFT LEVER
8
SCREW SHIFT LEVER TO TRANSMISSION
11
NUT BATTERY CABLE
11
NUT BRACKET TO SUPPORT AND TO END PIECE
14
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
17
VIBRATION ABSORBER
20
20
BOLT. SCREW VIBRATION ABSORBER TO BRACKET M 10X55
23
SCREW RADIATOR M 10X45
23
SCREW , Replaced By: N000000001441
26
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
29
NUT BATTERY CABLE
29
NUT BRACKET TO SUPPORT AND TO END PIECE
32
CONNECTOR SHIFTING ROD TO TRANSMISSION
35
38
SCREW , Replaced By: N304017008018
38
SCREW PUMP TO FRAME SIDE MEMBER M 8X40
41
NUT , Replaced By: N913004008001
41
NUT BRACKET TO BRACKET
44
BRACKET VIBRATION ABSORBER TO TRANSMISSION
47
SCREW BRACKET TO TRANSMISSION M 16 X 1,5 X 20
47
SCREW SHACKLE TO CONSOLE
50
LOCK WASHERROCKINGER TYP 59 G140,59 G150
