Поз.
Артикул
Описание
5
BRACKET FENDER
8
SUPPORT (CONSOLE),FOR FENDER
17
SCREW , Replaced By: N910105014010
17
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
26
NUT , Replaced By: N910113014001
26
NUT PARTICLE FILTER M14
29
WASHER FENDER BRACKET TO SIDE MEMBER
35
SCREW , Replaced By: N910142008009
35
SCREW , Replaced By: N304017008034
38
NUT , Replaced By: N913004008001
38
NUT BRACKET TO BRACKET
41
DAMPING STRIP (SOUND INSULATION),RIGHT
41
DAMPING STRIP (SOUND INSULATION),LEFT
44
BRACKET LEFT
44
BRACKET RIGHT
47
BRACKET RIGHT
47
BRACKET LEFT
50
BRACKET LEFT
50
BRACKET RIGHT
53
RIVET BRACKET TO ANTINOISE CAPSULE
56
CLAMP , Replaced By: A3099950140
59
SCREW , Replaced By: N910142008001
59
SCREW , Replaced By: N304017008021
62
NUT , Replaced By: N913004008001
62
NUT BRACKET TO BRACKET
65
BRACKET RIGHT FENDER
65
BRACKET LEFT FENDER
68
SCREW , Replaced By: N910105014010
68
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
71
NUT , Replaced By: N910113014001
71
NUT PARTICLE FILTER M14
74
BRACKET OIL REFILLING
77
SCREW , Replaced By: N910105010009
77
SCREW BRACKET TO SIDE MEMBER
80
NUT , Replaced By: N910113010000
80
NUT EXHAUST PIPE TO SIDE MEMBER
83
COVER ENGINE COVERING, FOR USE WITH SHORT MERCEDES-BENZ CAB
86
SHIM COVER PLATE TO CAB REAR PANEL, FOR USE WITH SHORT MERCEDES-BENZ CAB
89
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
999
BRACKET , Replaced By: A6455200241
999
BRACKET , Replaced By: A6455203841
