Поз.
Артикул
Описание
5
STOP
5
STOP
8
NUT ,B 884219
11
PEDAL PLATE ACCELERATOR PEDAL
14
ARTICULATION PIECE ACCELERATOR PEDAL
17
PIN ACCELERATOR PEDAL TO JOINT
20
WASHER GROUND CABLE
23
COTTER PIN STRAP TO BRACKET
26
SCREW ARTICULATION ELEMENT TO FLOOR M8X20,D 209703
29
SHEET METAL SCREW ACCELERATOR PEDAL TO FLOOR PLATE
32
ROD FROM ACCELERATOR PEDAL TO CONTROL LEVER
32
ROD ACCELERATOR PEDAL TO LEVER 151 MM,D 351515
35
NUT BATTERY CASE
38
BALL SOCKET ROD TO BALL PIVOT
44
PIN ROD TO PEDAL PLATE
47
WASHER GROUND CABLE
50
COTTER PIN ROLLER TO LEVER
53
LEVER (DOUBLE LEVER)
53
LEVER , Replaced By: A3823008128
59
BUSHING , USED WITH AIR BRAKE
62
FITTED WASHER , USED WITH AIR BRAKE
65
LOCK RING PIN TO BEARING BRACKET, 380.017,080,081,180,181 ONLY FOR SHORT CAB MERCEDES-BENZ
68
BALL PIVOT , Replaced By: A3129910120
71
BALL PIVOT
74
GREASE NIPPLE
74
GREASE NIPPLE PROTECTIVE TUBE
77
SCREW BRACKET TO FRAME
83
NUT BRACKET TO BATTERY CASE
89
PULL ROD LEVER TO LEVER
95
NUT
98
BALL SOCKET PULL ROD TO LEVER
104
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
107
YOKE FROM REVERSING LEVER TO CONTROL LEVER
113
BRACKET CONTROL,FRONT
122
SCREW BRACKET TO FRAME
128
NUT BRACKET TO BATTERY CASE
137
LEVER ACCELERATOR PEDAL CONTROL
140
BUSHING , USED WITH AIR BRAKE
143
FITTED WASHER , USED WITH AIR BRAKE
146
LOCK RING PIN TO BEARING BRACKET, 380.017,080,081,180,181 ONLY FOR SHORT CAB MERCEDES-BENZ
149
GREASE NIPPLE
