Поз.
Артикул
Описание
26
EXPANSION PLUG P.T.O., 401 259615 402 259609 403 259824 404 006166 421 070919 422 070623 423 075287 424 000772
48
HOUSING P.T.O.
48
HOUSING P.T.O., TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
48
HOUSING , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401-403,421-423,440-443,445,446 938431 404,424,444 020000, Replaced By: A5422340020
48
HOUSING P.T.O., Replaced By: A4572340020
48
HOUSING P.T.O.
48
HOUSING P.T.O., TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
104
SHAFT
156
SEAL RING HOUSING WITH FLANGE,GASKET AND COVER TO TIMING CASE
192
GEAR , 401-403 083702 404 000681, Replaced By: A4032340525, +001A4032341405
192
GEAR (DRIVE GEAR),P.T.O.
204
NUT DRIVE GEAR TO P.T.O. SHAFT
264
SCREW , Replaced By: N304017008027
264
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
264
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
276
SCREW CONTROL VALVE ON CAB BRACKET M 8X25
276
SCREW ON STOP M 8X65
276
SCREW. CAP BOLT FLANGE TO PUMP, Replaced By: N000912012204
276
SCREW , Replaced By: N304014008002
276
SCREW SHEAVE PULLEY TO BRACKET M8X40
276
SCREW CLAMP ON BRACKET
276
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
276
SCREW VALVE TO BRACKET
288
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
290
SPRING WASHER , Replaced By: N000137008212
290
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
312
NUT
312
NUT , Replaced By: N304032008006
336
OIL NOZZLE LUBRICATION OF P.T.O.
336
OIL NOZZLE LUBRICATION OF P.T.O.
372
SCREW BRACKET MOUNTING
372
HEXAGON HEAD BOLT BRACKET TO SIDE MEMBER M12X1.5X40
372
SCREW INTERMEDIATE FLANGE TO BEARING HOUSING
372
HEXAGON HEAD BOLT AIR DEHYDRATOR TO BRACKET M12X55,V 207570
384
LOCK WASHER FITTING TO BRACKET
396
FLANGE , Replaced By: A4422360445
396
FLANGE
420
BUSHING
438
SHAFT TIMING CASE
450
SEAL RING
462
LEVER (SHIFT LEVER),768698
462
LEVER (SHIFT LEVER)
474
SCREW , Replaced By: N304017006012
474
SCREW , Replaced By: N000000001479
474
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
474
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
474
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
486
NUT BALL PIVOT TO LEVER
486
NUT , Replaced By: N913023006001
486
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
487
FLANGE P.T.O., 401-403 083703 404 000682
490
SEAL RING
498
HYDRAULIC PUMP
569
FLANGE TO LOCK HOLE IN INTERMEDIATE FLANGE
570
GASKET TO LOCK HOLE IN INTERMEDIATE FLANGE
582
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
594
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
596
SCREW CONNECTOR TO CYLINDER HEAD M 8X25
596
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
720
HUB HYDRAULIC PUMP
722
WASHER HYDRAULIC PUMP
724
SCREW BRACKET TO APPARATUS SUPPORT
724
SCREW STOP TO BATTERY CASE
724
SCREW , Replaced By: A0069909301
726
SHIFTING COLLAR
727
GUIDE
729
GASKET HYDRAULIC PUMP
729
GASKET TO LOCK HOLE IN INTERMEDIATE FLANGE
732
SCREW CONNECTOR TO REAR SHIFTING ROD
732
SCREW , Replaced By: N304017010047
734
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
749
SCREW BRACKET TO ENGINE
752
COUPLING , Replaced By: A4422360636, +001A4422360736, +001A4422360085
752
COUPLING , Replaced By: A4422360436, +001A4422360536, +001A4422360085
755
HUB P.T.O. SHAFT
755
HUB P.T.O. SHAFT
758
HUB SUPPLIED LOOSE
758
HUB SUPPLIED LOOSE
761
FOLLOWERTO 442 236 04 36,05 36,
763
SCREWTO 442 236 04 36,05 36
766
RUBBER BUFFER SUPPLIED LOOSE
999
REPAIR KIT DRIVE MOUNTING PARTS, NO LONGER AVAILABLE
999
REPAIR KIT LOCK RING, NO LONGER AVAILABLE
999
SEAL RING INTERMEDIATE FLANGE
999
FLANGE GASKET COVER TO TIMING CASE
999
SPACER TUBE FUEL LINE TO BRACKET
999
GASKET COVER TO TIMING CASE, Replaced By: A0259976947
999
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
999
CAP TO PLUG AIR COMPRESSOR,REAR
999
GASKET , Replaced By: A4422340080
999
GASKET , Replaced By: A4422340180
999
SPACER TUBE P.T.O.
999
SPACER TUBE
999
SPACER TUBE HOUSING WITH FLANGE,GASKET AND COVER TO TIMING CASE
999
FLANGE , Replaced By: A4032360845
999
SCREW
999
EXPANSION PLUG SUPPORT TO SIDE MEMBER
999
GASKET
999
HOUSING , Replaced By: A4072340320
999
GASKET , Replaced By: A4442340080
999
FLANGE HYDRAULIC PUMP TO P.T.O.
999
FLANGE P.T.O.
999
STOP (SHIFT LEVER),768699
999
LEVER (SHIFT LEVER),768699
999
LEVER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421440635
999
HUB
999
HUB
999
SPACER TUBE (SHIFT LEVER),768699
999
FLANGE
999
FLANGE P.T.O.
999
HOUSING P.T.O., TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
FLANGE P.T.O., TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
FLANGE P.T.O., TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
SHAFT P.T.O., TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER PULL ROD TO SHIFT LEVER
999
WASHER BRACKET TO CROSS MEMBER
999
GROOVED BALL BEARING OUTPUT SHAFT
999
SCREW , Replaced By: N000912006064
999
SCREW
999
SCREW , Replaced By: N000912008202
999
SCREW. CAP BOLT COVER TO CASE M8X25
999
SCREW BRAKE CYLINDER TO BRAKE ANCHOR PLATE
999
CYLINDR. ROLLER BEARING P.T.O.
999
SCREW HOUSING WITH FLANGE,GASKET AND COVER TO TIMING CASE M 8X30
999
SCREW BRACKET TO EXHAUST PIPE BRACKET
999
SCREW HOUSING WITH FLANGE,GASKET AND COVER TO TIMING CASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
999
ROUND SECTION SEAL RING HOUSING WITH FLANGE,GASKET AND COVER TO TIMING CASE, TO BE ORDERED ONLY FROM MTU-FRIEDRICHSHAFEN
