Поз.
Артикул
Описание
181
PULL ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING, TO BE ADAPTED DURING ASSEMBLY
181
PULL ROD LOAD SENSOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
185
BALL SOCKET ACCELERATOR CONTROL
185
BALL SOCKET TO BE EXCHANGED FOR 000 991 24 22
185
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
185
BALL SOCKET PULL ROD TO LEVER
185
BALL SOCKET , Replaced By: A0009915222
185
BALL SOCKET ,266368
189
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
193
NUT L.H. THREAD
193
NUT BALL PIVOT TO LEVER
462
HEXAGON HEAD BOLT
462
SCREW , Replaced By: N910105006002
630
BRACKET
632
BRACKET IDLING SPEED STOP CYLINDER
634
BRACKET CHARGE AIR PIPE TO TRANSVERSE CHARGE AIR PIPE
634
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4410982239
636
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
638
REGULATING UNIT
638
REGULATING UNIT , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 258570/92, Replaced By: A0000720265
640
MOTOR SERVOMOTOR
642
MOTOR FINAL CONTROL ELEMENT
643
REPAIR KIT REGULATING UNIT
644
STUD BOLT STAY TO BRACKET AND TO SIDE MEMBER M 8X22
646
NUT , Replaced By: N304035008001
646
NUT
648
NUT , Replaced By: N304032008006
648
NUT
650
NUT PUMP TO BRACKET
650
NUT , Replaced By: N913004006001
652
GROMMET , Replaced By: A1029970081
652
GROMMET ACTUATOR TO BRACKET
654
SPACER TUBE OIL LINE TO BRACKET,K 093236
656
WASHER ACTUATOR TO BRACKET
658
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
658
SCREW , Replaced By: N000000001479
660
SPRING WASHER LICENSE PLATE TO BRACKET
662
LEVER , Replaced By: A4420704321
664
BALL PIVOT
666
BALL PIVOT
667
SEAL RING MODULATION PRESSURE CONTROL
668
NUT PUMP TO BRACKET
668
NUT , Replaced By: N913004006001
670
SCREW COVER TO THERMOSTAT HOUSING
672
WASHER , Replaced By: N009021006208
672
WASHER COMPRESSED AIR LINE TO BRACKET
674
NUT BALL PIVOT TO LEVER
676
NUT SPRING-LOADED PUSH ROD
678
CYLINDER INJECTION PUMP CONTROL
678
CYLINDER , Replaced By: A0000721512
680
NUT , Replaced By: A0009900851
680
NUT
682
BALL SOCKET
683
SEAL RING MODULATION PRESSURE CONTROL
684
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
686
LEVER (CONTROL LEVER),INJECTION PUMP
688
LEVER (CONTROL LEVER)
690
WASHER COVERING TO CAB
692
BALL PIVOT
694
BALL PIVOT ROD TO INJECTION PUMP LEVER
695
SEAL RING MODULATION PRESSURE CONTROL
696
NUT PUMP TO BRACKET
696
NUT , Replaced By: N913004006001
999
CYLINDER , Replaced By: A0000702183
999
CYLINDER , Replaced By: A0000702183
999
CYLINDER SHUT-OFF CYLINDER
999
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
999
REPAIR KIT
999
REPAIR KITTO 000 070 17 83
999
BUFFER BUFFER TO SUPPORT
999
HOLLOW SCREW FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
999
GREASE NIPPLE
999
RUBBER BUFFER BUFFER TO SUPPORT
999
FITTING
999
BALL PIVOT INJECTION PUMP
999
BEARING BRACKET
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
ROD (PUSH ROD)
999
LEVER
999
BRACKET COMPRESSED AIR CYLINDER
999
LEVER
999
LEVER ,253411
999
PIVOT PIN
999
SPACER TUBE CONTROL
999
BUSHING
999
BUSHING MOUNTING
999
BRACKET FINAL CONTROL ELEMENT
999
SCREENING PLATE
999
BEARING TUBE
999
SHIM
999
SHAFT
999
LEVER
999
LEVER
999
BEARING BRACKET
999
THREADED UNION , Replaced By: A4470720082
999
BEARING BRACKET
999
BRACKET
999
DIAL
999
PIN (INTERMEDIATE SHAFT)
999
BEARING BRACKET
999
SHAFT
999
BEARING TUBE
999
LEVER
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
BRACKET BRACKET TO TIMING CASE COVER
999
BRACKET BRACKET TO INJECTION PUMP
999
SPRING
999
LEVER (DOUBLE LEVER), FROM ENGINE 616807,ALSO INSTALLED ON 616100
999
BRACKET INTERMEDIATE AXLE
999
LEVER (DOUBLE LEVER)
999
SHAFT
999
SHAFT (INTERMEDIATE SHAFT)
999
BRACKET INTERMEDIATE AXLE
999
BEARING TUBE
999
LEVER FINAL CONTROL ELEMENT
999
CAP TO PLUG AIR COMPRESSOR OPENING,128243
999
ROD ACCELERATOR PEDAL TO LEVER
999
THREADED UNION OPERATING ROD
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
NUT , Replaced By: N304035008001
999
LOCK RING SHOCK ABSORBER TO BRACKET,1D 006005
999
SCREW , Replaced By: N304017006012
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW , Replaced By: N304017010028
999
NUT L.H. THREAD
999
NUT , Replaced By: N304032008006
999
WASHER BEARING BRACKET TO BRACKET
999
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
999
BALL STUD. BALL PIVOT TOP B10X4,5 MM
999
BALL PIVOT , Replaced By: A3129910120
999
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
999
PULL ROD FROM CONTROL SHAFT BEARING TO INTERMEDIATE LEVER 400 MM, TO BE ADAPTED DURING ASSEMBLY
999
PULL ROD FROM REAR CONTROL LEVER TO CONTROL SHAFT 600 MM, TO BE ADAPTED DURING ASSEMBLY
999
PULL ROD BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
999
PULL ROD SHIFTING ROD
999
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
999
NUT HEATING PIPE TO BRACKET
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
