Поз.
Артикул
Описание
86
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
89
FITTING (PARTS KIT),LINE RUPTURE
92
UNION NUT LINE CONNECTION, Replaced By: N000000006239
92
UNION NUT LINE CONNECTION
95
GLAND , Replaced By: N003861012007
98
SLEEVE LINE CONNECTION
113
FITTING12X1.5/M16X1.5 RAUFOSS
118
FITTING8X1/M12X1.5 RAUFOSS
119
FITTING8X1/M16X1.5 RAUFOSS
132
ELBOW FITTINGP5/12X1.5/90GR
134
ELBOW FITTINGP5/8X1MM/90GR
146
FITTINGP5/M12X1.5 RAUFOSS
148
FITTINGP5/M16X1.5
149
FITTINGP5/M22X1.5 RAUFOSS
164
FITTINGM22X1.5/M16X1.5 RAUFOSS
165
FITTINGM22X1.5/M16X1.5/M22X1.5 RAUFOSS
213
T-FITTINGM16X1.5/M16X1.5/P5 RAUFOSS
233
PIPE BENDM22X1.5/M16X1.5 RAUFOSS
256
CORNER BLOCKM16X1.5/M16X1.5/M16X1.5/P5 RAUFOSS
263
NUT WITH O-RING M22X1.5 RAUFOSS
267
NUTM22X1.5
292
DISTRIBUTOR8XM16X1.5 RAUFOSS
427
BRACKET
430
SCREWM 10X20
433
SCREW PIPE ELBOW TO BRACKET M8X12
433
SCREW SPEED SENSOR TO REAR AXLE
436
SCREW , Replaced By: N910143008009
439
NUT HORN TO BRACKET M8
442
BRACKET
445
SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION
448
SCREW
451
LOCK
454
WASHER BRACKET TO BATTERY CASE BRACKET
457
HEXAGON HEAD BOLT BOTTOM
460
LOCKS4
