Поз.
Артикул
Описание
80
PUMP WATER FLUSH
80
PUMP CHEMICAL FLUSH
80
WATER PUMP WATER FLUSH
81
REPAIR KIT
82
REPAIR KIT
83
HOSE PVC 13X3, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
84
CONTROL STOP. FASTENER CONTROL STOP
86
FITTING T SCREW-IN FITTING
89
CLAMP12-22
92
CLAMP8-16
95
HOSE COMPRESSED AIR HOSE, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
98
NOZZLE FLUSHING NOZZLE
101
FITTING ANGULAR SCREW FITTING 8 R1/4"
105
WC FLUSHING TRAY
105
TOILET BOWL FLUSHING TRAY
108
DISCHARGE FITTING
108
ADAPTER
111
SHUTOFF SLIDE
114
CLAMP INTAKE MUFFLER TO BRACKET 90-110X12
114
CLAMP HOSE TO PIPE ELBOW 90-110X12MM
117
HOSE RUBBER BOOT
123
HOSE
126
BLOWER24V
127
RECEPTACLE FECES CONTAINER
129
CLAMP20-32
132
FITTING ANGULAR SCREW FITTING WES 25 / R 1"
132
FITTING. ANGLE ANGULAR SCREW FITTING 19 R3/4"
138
ANGLE. FITTING ANGULAR SCREW FITTING 12/R1/2
141
GROMMET , Replaced By: A3019970481
141
GROMMET
144
SWITCH WASHER WATER LEVEL SENDER UNIT
147
PUMP FECES
151
HOSE BLUE, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
151
HOSE NATURAL, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
153
TUBE
154
SEAL CONE
177
VALVE
180
VALVE COMPLETE
181
VALVE (SOLENOID VALVE)
182
SEAL
183
FITTING
183
FITTING ANGULAR SCREW FITTING
186
FITTING SCREW-IN FITTING 6/R1/4
186
SCREW-IN JOINT U119/R3/4"
192
PUMP
192
CENTRIFUGAL PUMP , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.12.2008
192
HIGH-PRESSURE PUMP , Replaced By: A0028354264
192
PUMP , Replaced By: Q7731000501
195
HOSE EVACUATION 6X1MM, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
195
PLASTIC PIPE RISING PIPE 4X6 MM
198
STRAINER
199
SEAL
201
GROMMET
246
COVERING FECES CONTAINER
246
HINGED DOOR MAINTENANCE OPENING
247
COVERING WASTE PUSHER
247
COVERING
999
LEAF SPRING
999
COMPRESSED AIR LINE
999
SCREW-IN FITTING EVACUATION
999
ANGLE SCREW-IN FITTING EVACUATION
999
THREADED CONNECTION
999
ADAPTER
999
SEAL
999
HOSE5X1,5, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
HANDLE
