Поз.
Артикул
Описание
80
EDGE GUARD SECTION , TO BE ADAPTED DURING ASSEMBLY
80
EDGE GUARD SECTION UPPER LIGHT EXIT, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
83
LIGHT GUIDE , TO BE ADAPTED DURING ASSEMBLY
86
COVERING CRYSTAL CLEAR, TO BE ADAPTED DURING ASSEMBLY
89
DIODE GREEN LED
89
DIODE WITHE LED
89
DIODE BLUE LED
89
DIODE ORANGE LED
89
DIODE RED LED
92
COVERING
95
READING LAMP
98
BULB12 V / 5 W
101
DOME LAMP BLACK DECORATIVE RING
101
DOME LAMP SILVER DECORATIVE RING
101
DOME LAMP EVO GRAY
103
BULB HALOGEN 28 V / 20 W
105
REFLECTOR READING LAMP
107
BULB WITH REINFORCED COILED FILAMENT 24 V/10 W
109
REFLECTOR READING LAMP LED, UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)31.03.2011
109
REFLECTOR READING LAMP LED, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.04.2012
111
BORDER RING RIGHT
111
LENS LEFT
113
LENS OUTSIDE
113
BORDER RING INSIDE
116
INTERIOR LAMP
117
INTERIOR LIGHT STEPS LED, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)02.05.2005
117
DOME LAMP LUGGAGE COMPARTMENT,LEFT AND RIGHT LED
118
INTERIOR LAMP GREEN LED
119
BULB24 V 10 W
120
LAMP
122
TAPPING SCREW CONTROL UNIT TO FIRE WALL
122
SCREW2.9X16
122
SHEET METAL SCREW MODULE TO HOUSING
122
TAPPING SCREW MOUNTING, HANDLE MBN 10169-ST3.5X19-R
122
TAPPING SCREW RAIL
122
COUNTERSUNK WOOD SCREWST3,5X19, Replaced By: N000000000478
122
TAPPING SCREW3.5X19
125
PLATE DISTRIBUTOR BLOCK TO SUPPORT
129
COVER SUBSTRUCTURE STEP ILLUMINATION
131
FLUORESCENT TUBEL889 MM / 21W,WKK 629410 13 000245
131
FLUORESCENT TUBEL1189 MM / 28W,WKK 629410 13 000246
132
SEAL RING RIGHT SPRING-LOAD ACCUMULATOR 10X2.2
134
SERIES TRANSFORMER28 W,WKK 629410 13 000246
134
SERIES TRANSFORMER 21 W, HAPPICH, Replaced By: A6298270045
134
CONTROL UNIT 21 W, HAPPICH
134
BALLAST CONTOLER28 W
137
SOCKET
140
ELECTRIC CABLE
143
ELECTRIC CABLE INTERIOR LIGHTING,RIGHT
143
ELECTRIC CABLE INTERIOR LIGHTING,LEFT
149
BRACKET
149
SOCKET , Replaced By: A6298250314
152
BRACKET FLOURESCENT TUBES,WKK 629410 13 000246
155
COVERING LENS, TO BE ADAPTED DURING ASSEMBLY
158
COVERING LENS, TO BE ADAPTED DURING ASSEMBLY
999
LOOM TIE
