Поз.
Артикул
Описание
17
SCREW BRACKET AND CLAMP M6X20
20
NUT , Replaced By: N913023006001
20
NUT BRACKET TO FIRE WALL
26
SEAL RINGTO 006 997 00 72
26
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
29
HOLLOW SCREW LINE CONNECTION TO TRANSMISSION
32
CLAMP LINE MOUNTING 8/15
32
MOUNTING CLAMP22/15
32
CLAMP SUCTION/DELIVERY/RETURN LINES 12/15MM
32
CLAMP10/15
32
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
32
CLAMP LINE MOUNTING 10/15, Replaced By: N000000007511
32
CLAMP
32
CLAMP22/15, Replaced By: A0019951442
32
CLAMP ,K 147121, Replaced By: N000000000319
32
CLAMP , Replaced By: N916016010211
32
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
32
CLAMP DELIVERY AND SUCTION LINES TO FRAME
47
HOLLOW SCREW
47
HOLLOW SCREWB10
47
SCREW
50
WASHER
59
GROMMET
62
FITTING
62
FITTING
65
T-FITTING
68
LOCK. NUT , Replaced By: A0039941745
71
BRACKET
74
FITTING
74
HOLLOW SCREW FITTING AIR RESERVOIR,CONNECTION: "21",5 181510
77
FUEL HOSE
77
FUEL HOSE , AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.12.2011 UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 30.04.2012
86
FUEL LINE1750MM
86
FUEL LINE1790MM
89
FUEL LINE1960MM
89
LINE
92
LINE1530MM
92
FUEL LINE1558MM
95
LINE1820MM, UP TO PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS) 01.06.2008
98
FUEL LINE1800MM
98
FUEL LINE1886MM
101
FUEL LINE3121MM
101
FUEL LINE3060MM
104
FUEL LINE3100MM
107
TRANSPARENT CABLE13X1.5, AS OF PRODUCTION BREAKPOINT (DISCONTINUATION DATE FOR BCS)01.05.2012 ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
110
BANJO UNION10/14MM
113
FITTING RETURN LINE,K 169122
116
NUT LINE CONNECTION
119
FUEL HOSE
119
FUEL HOSE
122
FITTING LINE CONNECTION
125
NUT HORN TO BRACKET M8
128
SCREW BRACKET TO CAB REAR PANEL M 8X20
131
FUEL HOSE
131
FUEL HOSE
134
FITTING ON INTAKE RADIATOR-CONTROL MODULE,*0000058
