Поз.
Артикул
Описание
372
FILTER PRE-CLEANER
372
FUEL FILTER FUEL FEED PUMP
380
FILTER BOWL
382
FILTER ELEMENT , Replaced By: A0000910840
384
SPRING
386
SEAL RING
392
CLAMPING BRACKET PARTS KIT
522
PUMP (MANUAL AUXILIARY PUMP)
522
PUMP (MANUAL AUXILIARY PUMP)
524
SEAL RING
526
TRANSFER NIPPLE. FITTING
528
SEAL RING
530
REPAIR KIT VALVE
531
SPACER TUBE MANUAL FEED PUMP TO AIR INTAKE PIPE
531
SPACER TUBE ,014126 EXHAUST STOCK OF OLD PARTS UP TO ENGINE 015976, Replaced By: A4429915540
532
SCREW , Replaced By: N304017006012
532
SCREW , Replaced By: N304017006020
532
SCREW , Replaced By: N000933008337
532
SCREW , Replaced By: N304017008034
532
SCREW , Replaced By: A0099900101
532
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
532
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
532
SCREW 3/2-WAY VALVE TO BRACKET
532
SCREW COVER PLATE TO BRACKET
532
SCREW CONNECTOR TO TRANSMISSION
532
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
532
SCREWM 8X40
532
SCREW LICENSE PLATE TO BRACKET
532
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
532
SCREW BRACKET AND CLAMP M6X20
532
SCREW BRACKET TO CROSS CONNECTION STRUT
534
BRACKET (MANUAL FEED PUMP)
536
SPRING WASHER , Replaced By: N000137008212
536
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
536
SPRING WASHER LICENSE PLATE TO BRACKET
538
NUT SPRING-LOADED PUSH ROD
538
NUT , Replaced By: N304032008006
538
NUT
542
BANJO UNION FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
544
HOLLOW SCREW FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
546
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
546
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
555
FUEL FILTER PRE-CLEANER
556
FUEL FILTER FUEL FEED PUMP
557
FUEL PUMP (MANUAL FEED PUMP)
557
FUEL PUMP MANUAL PUMP AND PREFILTER
557
FUEL PUMP (MANUAL FEED PUMP)
558
FILTER ELEMENT PARTS KIT,014126
558
TS FILTER INSERT PARTS KIT
558
FILTER ELEMENT , Replaced By: A0000901951
558
FILTER ELEMENT PARTS KIT, Replaced By: A0000902051
558
FILTER ELEMENT , Replaced By: A0000900751
559
SEAL RING , Replaced By: A0000922960
559
SEAL RING
559
SEAL RING
560
FILTER BOWL
560
FILTER BOWL
561
COVER
562
HOUSING
563
FILTER BOWL
564
FILTER ELEMENT WITH SEAL RING
564
FILTER ELEMENT , Replaced By: A0000900451
565
FILTER ELEMENT , Replaced By: A0000910840
566
SPRING
567
SEAL PRE-CLEANER,014125
568
SEAL RING
569
CLAMPING BRACKET PARTS KIT
570
SEAL HOLDER
571
SCREW PLUG
572
SEALING RING. SEAL RING
572
SEAL RING AT OPERATING VALVE
573
SCREW
574
SEAL RING , Replaced By: N007603008112
574
SEAL RINGTO 000 550 00 83
576
REPLACED BY. SCREW PLUG , Replaced By: N007604014106
576
SCREW PLUG , Replaced By: N007604014110
576
SCREW PLUG FUEL TANK
576
SCREW PLUG
578
SEAL RING FUEL LINE TO FEED PUMP
578
SEAL RING INJECTION PUMP
578
SEAL RINGTO 000 553 03 05,000 553 18 05,
587
FITTING WATER SEPARATOR
592
SEAL RING INJECTION PUMP
603
SCREW PLUG , Replaced By: N000908014009
603
SCREW PLUGTO 000 553 03 05,000 553 18 05,
605
SEAL RING INJECTION PUMP
999
CLAMPING BRACKET FILTER HOUSING TO PUMP
999
SEPARATOR (WATER SEPARATOR)
999
NUT
999
BANJO UNION FUEL LINES AND BREATHING
999
STUD
999
CLAMPING PIECE FUEL FILTER TO BRACKET,012710
999
FITTING RETURN
999
LOOM TIE LINE MOUNTING
999
FITTING FUEL LINE TO HAND PUMP
999
HOLLOW SCREW FUEL LINES TO SOLENOID VALVE
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
999
INTERMEDIATE PIECE AT INJECTION PUMP
999
LINE FROM FUEL DISTRIBUTOR TO FEED PUMP
999
LINE FROM INJECTION PUMP OVERFLOW VALVE TO T-FITTING
999
LINE FROM FUEL FILTER TO INJECTION PUMP
999
LINE FROM FUEL FEED PUMP TO DISTRIBUTOR,062710
999
BRACKET , Replaced By: A4220901241
999
FILTER , Replaced By: A4420900452
999
PLATE LINE MOUNTING,920657
999
LINE
999
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
999
LINE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION, NOT USED
999
LINE FROM FEED PUMP TO FILTER, NOT USED
999
LINE , Replaced By: A4470700432
999
LINE FROM FUEL FILTER TO INJECTION PUMP, NOT USED
999
LINE , Replaced By: A4470700332
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
LOCK WASHER BRACKET TO SUPPORTING ARM
999
NUT , Replaced By: N304032008006
999
WASHER , Replaced By: N007349008007
999
WASHER
999
SEAL RING SCREW PLUG
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
SCREW SUPPORT TO FENDER
999
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
999
COMBINATION BOLT LEFT & RIGHT CHARGE AIR PIPES TO CYLINDER HEAD M 8X93
999
NUT. UNION NUT RETURN
999
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
