Поз.
Артикул
Описание
20
INTAKE MANIFOLD (AIR INTAKE PIPE)
20
INTAKE MANIFOLD
20
INTAKE PIPE
26
INTAKE PIPE
30
INTAKE MANIFOLD (AIR INTAKE PIPE)
38
INTAKE MANIFOLD ,643730
38
INTAKE MANIFOLDTO GARRETT 003 096 57 99
38
INTAKE MANIFOLD AIR INTAKE PIPE
38
INTAKE MANIFOLD , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 755100, Replaced By: A4411401001
38
INTAKE MANIFOLDTO KKK 003 096 37 99, Replaced By: A4411401001, +001A4039970032, +001N007603026104
44
CAP AIR COMPRESSOR CONNECTION
46
INTAKE MANIFOLD , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 608645, Replaced By: A4411400301
46
INTAKE MANIFOLD AIR INTAKE PIPE
47
AIR INTAKE PIPE
49
THREADED INSERT
62
BRACKET TO PLUG AIR COMPRESSOR OPENING
66
BRACKET INTAKE MANIFOLD
66
BRACKET AIR INTAKE PIPE
66
BRACKET
66
BRACKET COMPRESSED AIR LINES
70
CONNECTION PIPE SOCKET RIGHT
70
CONNECTION PIPE SOCKET
70
CONNECTION PIPE SOCKET EXHAUST GAS TURBOCHARGER
70
CONNECTION PIPE SOCKET
70
CONNECTION PIPE SOCKET
78
SEAL RING
82
SCREW FAN TO WATER PUMP M 8X80
82
SCREW , Replaced By: N000933008134
82
SCREW FRONT AXLE REGULATING SOLENOID VALVE
82
SCREW WATER PUMP TO CYLINDER CRANKCASE
86
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
86
SCREW CLAMP ON BRACKET
86
SCREW SUPPORT TO FENDER
86
BOLT. SCREW BRACKET TO PUSH ROD CHAMBER COVER
86
SCREW , Replaced By: N304017008018
86
SCREW , Replaced By: N304017008034
86
SCREW , Replaced By: N304017008033
86
SCREW BRACKET TO CROSS CONNECTION STRUT
86
HEXAGON HEAD BOLT SHIFT LEVER TO CAB FLOOR M 8X45
86
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
86
SCREW BRACKET TO TRANSMISSION
88
INTERMEDIATE PIECE ,627001
90
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
90
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
90
SCREW STOP TO BATTERY CASE
90
SCREW , Replaced By: N304017008027
90
SCREW , Replaced By: N304017008016
90
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
90
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
90
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
92
SCREW , Replaced By: N304017016011
92
SCREW INTERMEDIATE PIECE TO TIMING CASE,627001
92
SCREWM 16X25
94
WASHER EXHAUST MUFFLER TO STRAP
94
WASHER
94
WASHER , Replaced By: N000125008443
98
WASHER EXHAUST MUFFLER TO STRAP
98
SPRING WASHER SHIFTING CYLINDER TO YOKE
102
HEXAGON NUT. NUT , Replaced By: N913023008002
102
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
102
NUT STRAP TO SUPPORT,5 149419
182
CONNECTING PIPE AIR INTAKE PIPE TO TURBOCHARGER
182
CONNECTING PIPE AIR INTAKE PIPE TO TURBOCHARGER,643730
186
SEAL RING AIR INTAKE PIPE TO TURBOCHARGER
232
LOCKING CAP TO LOCK COOLING WATER BOTTOM OUTLET
232
LOCKING CAP TO PLUG INTAKE MANIFOLD AT AIR COMPRESSOR CONNECTION
232
LOCKING CAP , Replaced By: A3845067033
236
LOOM TIE , Replaced By: N000000000668
236
CLAMP , Replaced By: A0069970490
236
CLAMP , Replaced By: A0069970590
236
CLAMP25-40X13 MM
236
LOOM TIE
264
SLEEVE AIR INTAKE PIPE TO ENGINE
264
SLEEVE , Replaced By: A3669970283
268
LOOM TIE , Replaced By: A0069976090
268
CLAMP , Replaced By: N000000000674
268
CLAMP , Replaced By: A0069974490
268
CLAMP HOSE 70-90X13 MM
268
CLAMP W DRIVE A WASHER. CLAMP COVERING TO CAB
282
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
286
SCREW PLUG OIL COOLER,5 360280
286
SCREW PLUG , Replaced By: N000908026008
286
SCREW PLUG , Replaced By: A0009973532
292
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
292
SEAL RING AT AIR COMPRESSOR
292
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
300
FITTING AT AIR COMPRESSOR
999
THRUST RING SUCTION LINE TO OIL PUMP
999
LOCKING CAP
999
LOOM TIE , Replaced By: N916017025000
999
SLEEVE , Replaced By: A4229970083
999
SEAL RING LINE CONNECTION
999
LOOM TIE , Replaced By: N000000000668
999
SPACER RING PULLEY AND INTERMEDIATE PIECE TO WATER PUMP HUB
999
GASKET , Replaced By: A4421411480
999
GASKET , Replaced By: A4471410580
999
SPACER TUBE CABLE CONNECTOR BEHIND CAB,5 148678
999
GASKET , Replaced By: A4421410780
999
HOSE AIR COMPRESSOR CONNECTION
999
CONNECTOR
999
HOSE FROM AIR CLEANER TO INTAKE PIPE
999
CONNECTION PIPE SOCKET , Replaced By: A4041400037
999
CONNECTION PIPE SOCKET , Replaced By: A4241412157, +001N000908026005, +001N007603026106
999
CONNECTION PIPE SOCKET , Replaced By: A4241412257, +001N000908026005, +001N007603026106
999
INTAKE MANIFOLD , Replaced By: A4271410308
999
INTAKE MANIFOLD , Replaced By: A4411400401
999
BRACKET FUEL FILTER MOUNTED,645919
999
AIR INTAKE PIPE , SEE SA 18540/72
999
AIR INTAKE PIPE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 614576, Replaced By: A4420900629
999
BRACKET AIR INTAKE PIPE
999
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 614576, Replaced By: A4420980239
999
HOSE AIR-COMPRESSOR INTAKE PIPE CONNECTION
999
CONNECTOR , Replaced By: A4221400137
999
SLEEVE AIR INTAKE PIPE TO TURBOCHARGER
999
BRACKET
999
CONNECTION PIPE SOCKET , Replaced By: A4241410657, +004N007603026100, +004N007604026102
999
CONNECTION PIPE SOCKET , Replaced By: A4241410557
999
CONNECTION PIPE SOCKET , Replaced By: A4241411557
999
SHIM INTAKE MANIFOLD TO BRACKET,925974
999
AIR INTAKE PIPE
999
INTAKE PIPE
999
INTAKE PIPE , Replaced By: A4420982801, +001N000908026005, +001N007603026100
999
INTAKE PIPE
999
CAP TO PLUG AIR COMPRESSOR OPENING,128243
999
HOSE AIR-COMPRESSOR INTAKE PIPE CONNECTION
999
AIR INTAKE PIPE , NOT USED
999
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT,5 433388
999
SCREW PULLEY
999
WASHER , Replaced By: N007349008007
999
WASHER
999
SEAL RING LINE TO OIL PUMP
999
COMBINATION BOLT TO PLUG AIR COMPRESSOR OPENING
999
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
999
CLAMP , Replaced By: A0069970490
