Поз.
Артикул
Описание
11
BRACKET CONTROL LEVER
11
BRACKET , Replaced By: A4230900441
17
SCREW BRACKET TO SIDE MEMBER M 12X40
74
SHAFT (INTERMEDIATE SHAFT)
77
BALL PIVOT
77
BALL PIVOT LEVER
77
BALL PIVOT
77
BALL PIVOT , Replaced By: A3129910120
77
BALL STUD. BALL PIVOT TOP B10X4,5 MM
92
BUSHING MOUNTING
138
LEVER (CONTROL LEVER), WITH DIESEL ENGINE
138
LEVER , Replaced By: A3520709021
140
LEVER CONTROL LEVER
144
BALL PIVOT , Replaced By: A3129910120
144
BALL PIVOT
144
BALL PIVOT LEVER
145
PIN CONTROL LEVER TO BRACKET
146
RACE CONTROL LEVER TO BRACKET
147
INNER RING CONTROL LEVER TO BRACKET
148
NEEDLE BEARING CONTROL LEVER TO BRACKET
150
SCREW CAB FLOOR COVERING M 6X25
152
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
154
NUT SPRING-LOADED PUSH ROD
154
NUT BALL PIVOT TO LEVER
156
WASHER RADIATOR TO RUBBER MOUNTING
157
NUT BRACKET TO SUPPORT AND TO END PIECE
159
SPRING RELEASE SPRING, UP TO CHASSIS 556499 EXCEPT FOR 553795,555902,556120
258
SPACER TUBE FUEL FILTER TO CHARGING AIR PIPE
261
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
261
SCREW BEARING BRACKET TO CYLINDER CRANKCASE,602093
261
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
261
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
261
SCREW LEFT AND RIGHT CONSOLES TO CAB
261
SCREW , Replaced By: N308676012015
261
SCREW , Replaced By: N308676012011
265
SPRING WASHER CAB FLOOR
429
LEVER LOAD CONTROL, TO BE ADAPTED DURING ASSEMBLY
429
LEVER
429
LEVER , Replaced By: A4410700321
429
LEVER , Replaced By: A4410700621
429
LEVER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 671974, Replaced By: A4420703021
435
BALL PIVOT , Replaced By: A3129910120
435
BALL PIVOT LEVER
435
BALL PIVOT
459
SCREW COVER PLATE TO BRACKET
459
SCREW DELIVERY AND SUCTION LINES TO ENGINE, FRONT M 6X35
459
SCREW BRACKET ON LOAD SENSOR
465
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
550
PULL ROD FROM CONTROL SHAFT BEARING TO INTERMEDIATE LEVER 400 MM, TO BE ADAPTED DURING ASSEMBLY
550
ROD
550
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
550
PULL ROD BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
550
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
550
ROD (PUSH ROD)
550
ROD
550
ROD (PUSH ROD),SPRING-LOADED
550
ROD , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 098332, Replaced By: A4210700675
550
ROD (PUSH ROD)
550
ROD , Replaced By: A4010700675, +001A4070703675, +002N000934006007, +001N000934006012, +001N001479006001, +001N071805010204, +001N071805010403
550
ROD , Replaced By: A4010701275, +002N000934006007, +002N071805010204, +002N071805010403
550
ROD , Replaced By: N900331006630
550
ROD , Replaced By: A4010701575, +001A4070703675, +002N000934006007, +001N000934006012, +001N001479006002, +001N071805010204, +001N071805010403
555
ROD , Replaced By: A6583001715
555
ROD ACCELERATOR PEDAL TO LEVER
555
ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING
560
NUT
560
NUT BALL PIVOT TO LEVER
560
NUT , Replaced By: N304035008001
565
NUT L.H. THREAD
570
THREADED UNION , Replaced By: A4470720082
570
THREADED UNION OPERATING ROD
570
TURNBUCKLE TURNBUCKLE
575
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
580
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
999
CYLINDER , Replaced By: A0000702183
999
CYLINDER , Replaced By: A0000702183
999
CYLINDER SHUT-OFF CYLINDER
999
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
999
REPAIR KIT
999
REPAIR KITTO 000 070 17 83
999
BUFFER BUFFER TO SUPPORT
999
HOLLOW SCREW FOR HORIZONTAL MOUNTING OF HAND PUMP TO FEED PUMP
999
BALL SOCKET PULL ROD TO LEVER
999
BALL SOCKET ACCELERATOR CONTROL
999
GREASE NIPPLE
999
RUBBER BUFFER BUFFER TO SUPPORT
999
FITTING
999
BALL PIVOT INJECTION PUMP
999
BEARING BRACKET
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
ROD (PUSH ROD)
999
LEVER
999
BRACKET COMPRESSED AIR CYLINDER
999
LEVER
999
LEVER ,253411
999
PIVOT PIN
999
SPACER TUBE CONTROL
999
BUSHING
999
BRACKET FINAL CONTROL ELEMENT
999
SCREENING PLATE
999
BEARING TUBE
999
SHIM
999
SHAFT
999
LEVER
999
LEVER
999
BEARING BRACKET
999
THREADED UNION , Replaced By: A4470720082
999
BEARING BRACKET
999
BRACKET
999
DIAL
999
PIN (INTERMEDIATE SHAFT)
999
BEARING BRACKET
999
SHAFT
999
BEARING TUBE
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
LEVER (CONTROL LEVER),INJECTION PUMP
999
BRACKET BRACKET TO TIMING CASE COVER
999
BRACKET BRACKET TO INJECTION PUMP
999
SPRING
999
LEVER (DOUBLE LEVER), FROM ENGINE 616807,ALSO INSTALLED ON 616100
999
BRACKET INTERMEDIATE AXLE
999
LEVER (DOUBLE LEVER)
999
SHAFT
999
SHAFT (INTERMEDIATE SHAFT)
999
BRACKET INTERMEDIATE AXLE
999
BEARING TUBE
999
LEVER FINAL CONTROL ELEMENT
999
CAP TO PLUG AIR COMPRESSOR OPENING,128243
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
NUT , Replaced By: N304035008001
999
LOCK RING SHOCK ABSORBER TO BRACKET,1D 006005
999
SCREW , Replaced By: N304017006012
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW , Replaced By: N304017010028
999
NUT L.H. THREAD
999
NUT , Replaced By: N304032008006
999
WASHER BEARING BRACKET TO BRACKET
999
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
999
BALL PIVOT , Replaced By: A3129910120
999
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
999
NUT
999
PULL ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING, TO BE ADAPTED DURING ASSEMBLY
999
PULL ROD FROM REAR CONTROL LEVER TO CONTROL SHAFT 600 MM, TO BE ADAPTED DURING ASSEMBLY
999
PULL ROD SHIFTING ROD
999
NUT HEATING PIPE TO BRACKET
