Поз.
Артикул
Описание
318
GASKET CROSS CONNECTION TO CHARGING AIR PIPE, RIGHT AND LEFT
324
SCREW INTERMEDIATE PIECE AND PULLEY TO DAMPER M 10X30
436
OIL LINE FEED,LEFT
436
OIL LINE FEED,LEFT
436
OIL LINE FEED,LEFT
440
OIL LINE FEED,RIGHT
462
GASKET
462
GASKET FLANGE TO TURBOCHARGER
464
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
464
SPRING WASHER STEERING COLUMN BRACKET TO CAB
464
SPRING WASHER , Replaced By: N000137008212
468
SCREW , Replaced By: N304017010043
468
SCREW , Replaced By: N304017010036
468
SCREW BRACKET TO SIDE MEMBER M10X35
468
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
468
SCREW END PIECE TO EXHAUST PIPE M 10X25
468
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
468
SCREW BRACKET TO FRAME SIDE MEMBER
468
SCREW STOP TO BATTERY CASE
468
SCREW BRACKET TO CONSOLE
480
T-FITTING
530
HOLLOW SCREW FUEL LINE TO FEED PUMP
530
HOLLOW SCREW BREATHER PIPE TO CONNECTION FITTING
532
SEAL RING VALVE TO VALVE,K 025179
532
SEAL RINGTO 000 553 03 05,000 553 18 05,
540
OIL LINE TURBOCHARGER OIL FEED
540
OIL LINE TURBOCHARGER OIL FEED
540
EXPANSION PLUG OIL RETURN TO TIMING CASE
544
FITTING OIL RETURN TO TIMING CASE
564
INTERMEDIATE PIECE OIL PRESSURE GAUGE TO CYLINDER CRANKCASE
634
BRACKET
636
CLAMP LINE MOUNTING
638
SCREW CLAMP MOUNTING M 6X16
638
SCREW , Replaced By: N914146006102
640
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
642
NUT BALL PIVOT TO LEVER
644
SCREW BRACKET TO EXHAUST MUFFLER BRACKET
646
LOCK WASHER FITTING TO BRACKET
670
CLAMP LINES TO BRACKET
672
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
672
SCREW , Replaced By: N304017008034
674
WASHER , Replaced By: N000125008443
674
WASHER EXHAUST MUFFLER TO STRAP
676
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
678
NUT ENGINE MOUNTING M8
678
HEXAGON NUT. NUT , Replaced By: N913023008002
680
BRACKET OIL FEED LINE TO TIMING CASE
682
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
682
SCREW , Replaced By: N304017008016
684
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
686
NUT ENGINE MOUNTING M8
686
HEXAGON NUT. NUT , Replaced By: N913023008002
688
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
704
OIL LINE RIGHT OIL RETURN LINE
704
OIL LINE RETURN,RIGHT
704
OIL LINE LEFT OIL RETURN LINE TO TURBOCHARGER
704
OIL LINE LEFT OIL RETURN LINE
704
OIL LINE EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
704
OIL LINE RETURN,LEFT
712
GASKET HEATING PIPE TO ENGINE
712
GASKET
712
GASKET OIL RETURN LINE TO TURBOCHARGER
714
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
714
SPRING WASHER STEERING COLUMN BRACKET TO CAB
714
SPRING WASHER , Replaced By: N000137008212
716
SCREW VALVE TO BRACKET, Replaced By: N304014008002
716
SCREW , Replaced By: N304017010030
716
SCREW BRACKET TO SIDE MEMBER M10X35
716
SCREW 4/2-WAY VALVE TO BRACKET
716
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
716
SCREW BRACKET TO FRAME SIDE MEMBER
716
SCREW ON STOP M 8X65
716
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
716
SCREW END PIECE TO EXHAUST PIPE M 10X25
716
HEXAGON HEAD BOLT. SCREW ON STOP M 8X50
716
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
716
SCREW STOP TO BATTERY CASE
716
SCREW STRAP TO BRACKET
722
HOSE FUEL COMPENSATING, ORDER BY THE METER
722
HOSE , Replaced By: A0005514156
722
HOSE TURBOCHARGER OIL RETURN
724
LOOM TIE , Replaced By: N000000000668
724
CLAMP , Replaced By: A0069970490
724
CLAMP , Replaced By: A0069970590
724
CLAMP AT PRESSURE REGULATOR,4 281212 MODELS 002,003,006,007,009,034,UP TO CHASSIS 4 424733,MODELS 134 UP TO CHASSIS 4 611513
724
LOOM TIE
724
CLAMP25-40X13 MM
752
PIPE ELBOW EXHAUST GAS TURBOCHARGER OIL RETURN, RIGHT
824
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
824
SCREW FRONT AXLE REGULATING SOLENOID VALVE
824
SCREW STOP TO BATTERY CASE
824
SCREW , Replaced By: N304014008007
824
SCREW , Replaced By: N304017008016
826
NUT , Replaced By: N080705026003
826
NUT 3/2-WAY VALVE TO CAB,4 685151
999
REPAIR KIT TURBOCHARGER TO 003 096 55 99
999
REPAIR KIT TURBOCHARGER TO 004 096 05 99,06 99
999
REPAIR KIT , Replaced By: A0000900298
999
RUNNER PARTS KIT
999
REPAIR KIT TURBOCHARGER
999
RUNNER PARTS KIT
999
REPAIR KIT , Replaced By: A0005862609
999
REPAIR KIT TURBOCHARGER
999
RUNNER PARTS KIT
999
REPAIR KIT TURBOCHARGER,MAKE AIRESEARCH
999
REPAIR KIT TURBOCHARGER TO 004 096 92 99/90 99
999
REPAIR KIT TURBOCHARGER
999
RUNNER PARTS KIT TO 003 096 70 99,71 99
999
RUNNER PARTS KIT TO 003 096 55 99
999
RUNNER PARTS KIT
999
RUNNER , Replaced By: A0000902890
999
RUNNER PARTS KIT
999
RUNNER PARTS KIT TO 004 096 03 99,04 99
999
TURBINE WHEEL MAKE AIRESEARCH
999
TURBINE WHEEL
999
TURBINE WHEELTO 004 096 09 99/10 99/18 99/19 99
999
COMPRESSOR WHEELTO 003 096 23 99,24 99
999
SEAL RINGTO 401 142 02 09
999
CYLINDER
999
CYLINDER , Replaced By: A0004304926
999
REPAIR KIT TURBOCHARGER
999
CAP , Replaced By: A4039970086
999
NUT , Replaced By: A0009903150
999
STUD , Replaced By: A0019904605
999
STUD , Replaced By: A0009905705
999
SCREW PLUG OIL COOLER,5 360280
999
SLEEVE , Replaced By: A4229970083
999
TURBOCHARGER , ORDER NO. 001 096 44 99/34
999
TURBOCHARGER , ORDER NO. 001 096 45 99/33
999
TURBOCHARGER , Replaced By: A0010967299
999
TURBOCHARGER , Replaced By: A0010969199
999
TURBOCHARGER , Replaced By: A0020960499
999
TURBOCHARGER
999
TURBOCHARGER RIGHT, ORDER NO. 001 096 86 99/34
999
TURBOCHARGER , Replaced By: A0020961099
999
REPAIR KIT , Replaced By: A0024300060
999
TURBOCHARGER , Replaced By: A0030961699
999
TURBOCHARGER , Replaced By: A0030961699
999
TURBOCHARGER RIGHT
999
TURBOCHARGER , Replaced By: A0040960499
999
TURBOCHARGER , Replaced By: A0040960399
999
TURBOCHARGER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 019003 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0060960799
999
TURBOCHARGER RIGHT,019989
999
TURBOCHARGERKKK, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
SEAL RING , Replaced By: A0179971748
999
SPACER RING BRACKET TO TIMING CASE COVER
999
PIPE ELBOW , NOT USED
999
PIPE ELBOW BETWEEN FILTER AND BRACKET
999
ANGLE SHIFTING DOME
999
GASKET TURBOCHARGER TO EXHAUST COLLECTOR PIPE, NOT USED
999
THROTTLE VALVE , Replaced By: A3451440213, +001A3451400428
999
SHAFT THROTTLE VALVE,610644
999
GASKET , Replaced By: A4421870080
999
HOSE
999
HOSE , Replaced By: A3529973782
999
GASKET , Replaced By: A4421410780
999
HOSE (CHARGE AIR CONNECTING PIPE)
999
GASKET
999
INTAKE MANIFOLD (TRANSVERSE CHARGING AIR PIPE)
999
EXHAUST COLLECTOR PIPE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A4011420309, +001A4011400003, +001A4011400103
999
GASKET , Replaced By: A4421411380
999
FLANGE
999
TIMING CASE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A4030108233
999
TIMING CASE ,006166, Replaced By: A4230100833, +010A4039900504
999
GASKET , Replaced By: A4420150380
999
COVER , Replaced By: A4030150109, +002N000933008147, +002N912004008102
999
SCREENING , Replaced By: A4030700355
999
SCREENING , Replaced By: A4030700055
999
CAP , Replaced By: A4421310021
999
FITTING AIR COMPRESSOR,CONNECTION: "10"
999
HOSE
999
SCREW , Replaced By: A4479905204
999
FLANGE TO PLUG OIL RETURN BORE
999
CRANKCASE , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 001957, EXCEPT FOR 001655-001671, 001677-001716, 001720-001724, 001732-001735, 001748-001818,001933-001955 STANDARD VERSION FROM ENGINE 001958, Replaced By: A4040103008, +002A4031800011, +001A4041801538, +001A4421840580, +001A4031883701, +001A4032007001, +001A4422011080, +002A4039900301, +024A0009911341
999
SCREENING PLATE EXHAUST GAS TURBOCHARGER
999
HOSE , Replaced By: A4041410583
999
HOSE , Replaced By: A4041410583
999
GASKET , Replaced By: A4441420180
999
OIL LINE TURBOCHARGER OIL RETURN
999
OIL LINE RETURN,LEFT
999
OIL LINE TURBOCHARGER OIL RETURN
999
OIL LINE
999
OIL LINE FEED,RIGHT
999
OIL LINE OIL FEED LINE
999
OIL LINE FEED,RIGHT
999
OIL LINE FEED,LEFT
999
FITTING , Replaced By: A4031340156
999
CONNECTING PIPE
999
OIL LINE , Replaced By: A4071800320
999
OIL LINE , NOT USED
999
OIL LINE , Replaced By: A4071801122
999
OIL LINE , Replaced By: A4071801222
999
GASKET , Replaced By: A4471870080
999
GASKET , Replaced By: A4471870180
999
HOSE , Replaced By: A4969970582
999
BRACKET EXHAUST GAS TURBOCHARGER
999
PIPE ELBOW LEFT,421-017609
999
PIPE ELBOW RIGHT,421-017609
999
SCREW , Replaced By: A4479905304
999
AIR INTAKE PIPE
